Denon DRA-100

1.3. File structure on USB Memory
Copy the update les to the USB memory with the following structure.
USB memory root
Model Name Model Area Product ID
DRA-100
Europe (E2) 000200160200
Japan (JP) 000200160400
+ rmwares
+ 000200XXXXXX
+ enc_update.xml
+ IMG.bcd
+ SBL.bcd
+ SYS.bin
1.4. Insert the USB memory into the USB port.
NOTE : Remove the LAN cable from this unit when performing updates.
1.5. Start the update.
Press and hold the power operation button "
X
" before inserting the AC plug, then insert the AC plug while holding down
the button and wait for more than 3 seconds.
Select "
USB Update
" using "
CURSOR
d
" and "
CURSOR
f
", then press the "
Enter
" button to select.
1.6. Display during USB update
(1) The following message appears on the display.
Display
(2) Press "
ENTER
" key on Main unit
Then start Firmware Update.
Display
(3) The rmware update nishes.
The unit restarts after the update is nished.
---Cautions on Firmware Update---
• Never remove the USB memory before the update is nished.
• Never turn off the power before the update is completed.
• It takes around 0.5 hour to complete the update.
Once an update is started, normal operations cannot be performed until it is completed.
Also, setting items may be initialized.
Note down the settings before updating, and set them again after updating.
USB メモリへファー
ムウェアをダウンロー
ドしてください。
26
