53
DRA-295
PARTS LIST OF P.W.B. UNIT
MAIN P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
SEMICONDUCTORS GROUP
IC101 963 0057 903 IC KIA7815AP J126781500060
IC102 963 0044 806 IC NJM7915FA J126791500010
IC104 960 0196 001 IC NJM7805FA J126780500130
IC105 960 0195 808 IC ICP-N15 J120001500030
IC300 960 0174 308 IC TC9273N-007 J080927300000
IC301 960 0179 701 IC NJM2068DD J121206800000
Q101,102 960 0196 603 Transistor KTC2874B J502287400010
Q103-106 960 0196 205 Transistor KSA992Y J5000992F0050
Q107,108 960 0196 506 Transistor KSC1845F J5021845F0000
Q115,116 960 0196 506 Transistor KSC1845F J5021845F0000
Q117-119 963 0022 006 Transistor DTC114YS J6020114Y0050
Q120 960 0196 302 Transistor KTA1268BL J5001268B0050
Q121 960 0196 700 Transistor KTC3200BL J5023200B0050
Q122 960 0189 005 Transistor KSA916Y J5000916Y0050
Q123 960 0005 105 Transistor KTA1266Y J5001266Y0050
Q124 960 0005 202 Transistor KTC3198Y J5023198Y0000
Q125 960 0196 302 Transistor KTA1268BL J5001268B0050
Q126,127 960 0005 202 Transistor KTC3198Y J5023198Y0000
Q128 960 0196 302 Transistor KTA1268BL J5001268B0050
Q129,130 960 0005 202 Transistor KTC3198Y J5023198Y0000
Q131,132 960 0196 302 Transistor KTA1268BL J5001268B0050
Q133,134 960 0196 409 Transistor 2SC1740SR J5021740S0010
Q136 963 0022 006 Transistor DTC114YS J6020114Y0050
D101-113 963 0020 309 Diode 1SS133 K000013300520
D114-119 963 0058 407 Diode 1N4007 K000400700520
D120,121 963 0020 309 Diode 1SS133 K000013300520
D122-125 963 0058 407 Diode 1N4007 K000400700520
D126-129 963 0020 309 Diode 1SS133 K000013300520
D132-135 963 0020 309 Diode 1SS133 K000013300520
DB101,102 960 0197 107 Diode KBPC604 K047604000020
DZ101,102 963 0046 202 Zener diode MTZJ18B K06018R044520
DZ103,104 963 0047 405 Zener diode MTZJ7.5B K06007R544520
DZ105 963 0058 708 Zener diode MTZJ20B K06020R044520
DZ106 960 0095 500 Zener diode MTZJ5.1B K06005R144520
DZ107-110 963 0047 502 Zener diode MTZJ3.3B K06003R344520
RESISTORS GROUP
R117,118 960 9004 301 Metal film 47ohm 1/4W (NB) C060047063050
R127-130 244 2052 957 Metal film 5.6kohm 1W (NB) C060056265070
R135,136 963 9003 068 Metal film 4.7ohm 1/4W (NB) C0604R7063050
R137-140 244 2043 982 Metal film 0.22ohm 1W (NB) C060R22065070
R141,142 963 9003 068 Metal film 4.7ohm 1/4W (NB) C0604R7063050
R143-146 244 2043 982 Metal film 0.22ohm 1W (NB) C060R22065070
R153-156 244 2043 937 Metal oxide 10ohm 1W (NB) C041010065060
R162-164 244 2055 996 Metal film 1.2kohm 1W (NB) C060012265050
R165 244 2043 937 Metal oxide 10ohm 1W (NB) C041010065060
R166 244 2043 982 Metal film 0.22ohm 1W (NB) C060R22065050
R173 963 9003 068 Metal film 4.7ohm 1/4W (NB) C0604R7063050
R190,191 963 0045 203 Winding 0.1ohm 5W C144R10069110
R195,196 244 2043 982 Metal film 0.22ohm 1W (NB) C060R22065050
R208 963 9005 105 Carbon film 68ohm 1/4W C000068063520
R209 963 0043 108 Metal film 2.2Mohm 1/2W for E3
C060022574000
R343,344 244 2043 937 Metal oxide 10ohm 1W (NB) C041010065060
VR101,102 960 0091 601 Semi fixed resistor 1kohm C544102015130
CAPACITORS GROUP
C101,102 Electrolytic 22uF/50V D040220087060
C103,104 Electrolytic 10uF/50V D040100087070
C105,106 963 9005 118 Ceramic 100pF/50V D004101067060
C107,108 963 9003 165 Ceramic 220pF/500V D009092212500
C109,110 Electrolytic 47uF/25V D040470084070
C111,112 963 9005 121 Ceramic 33pF/500V D000330067050
C115,116 963 9005 134 Ceramic 1200pF/50V D004122287050
C117,118 Electrolytic 47uF/50V D040470087060
C119,120 963 9003 084 Ceramic 100pF/500V D00410106D050
C121,122 Electrolytic 10uF/50V D040100087070
C123,124 963 9003 084 Ceramic 100pF/500V D00410106D050
C125,126 963 9004 517 Ceramic 0.022uF/50V D004223597050
C127-130 963 9003 097 Mylar film 0.1uF/250V D02010407H080
C131-134 960 9003 409 Mylar film 0.01uF/50V for E2
D020103167050
C135 963 9004 504 Ceramic 0.01uF/50V D004103097060
C136 Electrolytic 2.2uF/50V D0402R2087100
C137 963 9004 504 Ceramic 0.01uF/50V D004103097060
C138,139 Electrolytic 1uF/50V D040010087080
C140 963 9005 147 Ceramic 0.1uF/25V D004104594050
C141 Electrolytic 220uF/6.3V D040221081230
C142 963 9005 147 Ceramic 0.1uF/25V D004104594050
C143 Electrolytic 220uF/6.3V D040221081230
C144,145 963 9005 150 Electrolytic 6800uF/63V D040681088030
C146-150 963 9003 097 Mylar film 0.1uF/250V D02010407H080
C151 Electrolytic 1uF/50V D040010087080
C152 963 9005 163 Electrolytic 1000uF/50V D040102087230
C153-155 963 0021 900 Mylar film 0.047uF/100V D02047306C060
C156 960 9007 201 Electrolytic 3300uF/35V D040332085010
C157 963 9003 123 Electrolytic 1000uF/35V D040102085040
C158,159 Electrolytic 10uF/50V D040100087070
C161 Electrolytic 10uF/50V D040100087070
C162 Electrolytic 4.7uF/50V D0404R7087100
C164 963 9003 136 Electrolytic 1000uF/25V D040102084060
C167,168 Electrolytic 1uF/50V D040010087080
C169 963 9005 176 Ceramic 4700pF/250V (AC) D008472089010
C170 963 9005 299 Electrolytic 100uF/100V D04010108C200
C174 Electrolytic 10uF/50V D040100087070
Note: The symbols in the column “Remarks” indicate the following destinations.
E3: U.S.A./Canada model E2: Europe model
