19
16-1. Release the clamp*2(follow Figure D&E).
16-2. Remove the solder *2.(follow Figure F&G) then remove the control 2 pcb ass'y.
17. Remove the square buttons and rotary buttons.
Release
the clamp
Figure D
Figure E
Figure F
Figure E
Release the
clamp
Remove
the solder
Remove
the solder
