CONRTOL_1
3
REF No. Part No. Part Name Remarks Q'ty New Ver
C109-111 nsp CHIP CAPACITOR(0.01uF/50V,J,0603 TAP,NPO 413-DCM280-889 3
C112 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 1
C113-127 nsp CHIP CAPACITOR(0.01uF/50V,J,0603 TAP,NPO 413-DCM280-889 15
C128 941134001550S
ELEC. CAPACITOR(10uF/16V,M,105℃,TAPING)
413-DV300-5155 1
C129 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 1
C131 00D9587054907
ELEC. CAPACITOR(100uF/10V,M,105℃,TAPING)
413-HMA2200-5017 1
C139 nsp CHIP CAPACITOR(1uF/16V,Z,0603 TAP,Y5V) 413-007USB-797 1
C140 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 1
C141 nsp CHIP CAPACITOR(12pF,50V,J,0603 TAP,NPO) 413-DCM280-809 1
C142 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 1
C143 nsp CHIP CAPACITOR(12pF,50V,J,0603 TAP,NPO) 413-DCM280-809 1
C144 00D9587054907
ELEC. CAPACITOR(100uF/10V,M,105℃,TAPING)
413-HMA2200-5017 1
C145 941135500070P TANTALUM CAPACITOR(0.68uF/50V,K,TAPING) 413-MAIE-1211 1
C146 nsp CHIP CAPACITOR(0.47uF/50V Y5V/0603 Z TAP) 413-CDVD2001-751 1
C147-150 nsp CHIP CAPACITOR(0.01uF/50V,J,0603 TAP,NPO 413-DCM280-889 4
C151 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 1
C152 00D9587054907
ELEC. CAPACITOR(100uF/10V,M,105℃,TAPING
413-HMA2200-5017 1
C153,154 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 2
C155 nsp CHIP CAPACITOR(1uF/16V,Z,0603 TAP,Y5V) 413-007USB-797 1
C156,157 nsp CHIP CAPACITOR(0.01uF/50V,J,0603 TAP,NPO 413-DCM280-889 2
C158 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 1
C159 nsp CHIP CAPACITOR(1000pF/50V,K,0603 TAP,X7R) 413-DCM280-768 1
C160-163 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 4
C164-166 nsp CHIP CAPACITOR(1uF/16V,Z,0603 TAP,Y5V) 413-007USB-797 3
C167 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 1
C168 nsp CHIP CAPACITOR(1000pF/50V,K,0603 TAP,X7R) 413-DCM280-768 1
C169 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 1
C170-176 nsp CHIP CAPACITOR(1800pF/50V,J,0603 TAP,NPO) 413-1400DSP-1028 7
C177-190 nsp CHIP CAPACITOR(3300pF/50V,K,0603 TAP,X7R) 413-DCM280-770 14
C191-196 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 6
OTHER PARTS GROUP
CN100TOCB2\\CN100 941644101890P 32P 1.0 FFC SOCKET 404-6K2-3827 1 *
CN102TOMAIN\\PCBCN102 941644101900P 24P 1.0 FFC SOCKET(SMD90°) 404-RECYCLE-3555 1 *
CN104TOFRONT\\PCBCN104 941644101430P 14P 1.0 FFC SOCKET(1.0D-14PBS) 404-3000-3620 1
CN105TOIOPC\B\W105 941644101910P 10P 1.0 FFC SOCKET(1.0D-10PBS,90°) 404-PDJ22-3567 1 *
EARTH1,2 941602100350P 1P GROUNG WIRE(L=55mm) 406-6K2-1275 2 *
J101,102 nsp CHIP RESISTOR(0 OHM,1/4W,J,1206,200V) 412-DJ3000-414 2
L100 nsp POWER CHOKE(22uH,1.11A) 415-MC6000-356 1
L101 nsp INDUCTOR(10uH T-26mm) 415-MPG100-047 1
L102,103 nsp INDUCTANCE(100uH J 0707-444-W077) 415-HT8015-040 2
SW100-102 941662001910S TACT SW(SFKHVBL3725,TAPING,H=7mm) 403-CDJ3300-195 3
SW103,104 941662100200P TACT SW 403-6K2-442 2
*
SW105 941662001910S TACT SW(SFKHVBL3725,TAPING,H=7mm) 403-CDJ3300-195 1
SW106 941662100200P TACT SW 403-6K2-442 1 *
SW107-125 941662001910S TACT SW(SFKHVBL3725,TAPING,H=7mm) 403-CDJ3300-195 19
SW126 941662100200P TACT SW 403-6K2-442 1 *
SW127-133 941662001910S TACT SW(SFKHVBL3725,TAPING,H=7mm) 403-CDJ3300-195 7
SW134 941662100200P TACT SW 403-6K2-442 1 *
SW135-137 941662001910S TACT SW(SFKHVBL3725,TAPING,H=7mm) 403-CDJ3300-195 3
SW138 941662100200P TACT SW 403-6K2-442 1 *
SW139-144 941662001910S TACT SW(SFKHVBL3725,TAPING,H=7mm) 403-CDJ3300-195 6
SW145 941663004650P SW(SR1712F-0104-20F0A-N9-N,SR1712F) 403-IQ2-339 1
SW146 90M-SR000310R ROTARY SWITCH(SR1712F-0102-20F0A-N9-N) 403-8001-261 1
SW147 941662100200P TACT SW 403-6K2-442 1 *
SW148,149 941662001910S TACT SW(SFKHVBL3725,TAPING,H=7mm) 403-CDJ3300-195 2
SW150 941667100150P ENCODER(L=20) 403-6K2-438 1 *
SW151-153 941662001910S TACT SW(SFKHVBL3725,TAPING,H=7mm) 403-CDJ3300-195 3
SW154 941667100150P ENCODER(L=20) 403-6K2-438 1 *
SW155,156 941662001910S TACT SW(SFKHVBL3725,TAPING,H=7mm) 403-CDJ3300-195 2
SW157 941662100200P TACT SW 403-6K2-442 1 *
SW158 941667100150P ENCODER(L=20) 403-6K2-438 1 *
SW159-163 941662001910S TACT SW(SFKHVBL3725,TAPING,H=7mm) 403-CDJ3300-195 5
SW164 941662100200P TACT SW 403-6K2-442 1 *
SW165,166 941662001910S TACT SW(SFKHVBL3725,TAPING,H=7mm) 403-CDJ3300-195 2
SW167 941662100200P TACT SW 403-6K2-442 1 *
SW168-170 941662001910S TACT SW(SFKHVBL3725,TAPING,H=7mm) 403-CDJ3300-195 3
SW171 941663004650P SW(SR1712F-0104-20F0A-N9-N,SR1712F) 403-IQ2-339 1
SW172 941663004660P ROTARY SWITCH(SR1712F-0102-20F0A-N9-N) 403-8001-261 1
SW173 941663004640P SW(SR1712F-0105-20F0A-N9-N,L=20) 403-MC6000-386 1
SW174 941664004680P SLIDE SW(SSH-13D03-G12-NS) 403-MC6000-391 1
W101TOIOPC\B\CN101 nsp 4P 2.5 CONNECTOR WIRE(L=70mm,+/+) 404-6K2-3829 1
W103TOCFPC\B\CN103 nsp 3P 2.0CONNECTOR WIRE 404-6K2-3828 1
X100 941141101060P CRYSTAL(HC-49S,24MHz,11.5*4.65MM) 427-S1-144 1 *
