CONRTOL_2
4
CONRTOL 2 PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed b
olumn Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D400-411 nsp SWITCHING DIODE(ISS355VM 1.7*1.25MM) 414-CD1000-075A 12
D412,413 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 2 *
D414,415 941176100190P
LED(AMBER,∮3,TAPING)
410-6K2-436 2 *
D416,417 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 2 *
D418 941263004490P LED ( LTL-1CHY,YELLOW ) 410-CD6000-123 1
D418 nsp LED HOLDER(LED3-1A-B,H=1.5mm,BLACK) 504-HDJ2000-097 1
D419,420 941176100180P
LED(YELLOW/GREEN,∮3,TAPING)
410-6K2-435 2 *
D421,422 941176100190P
LED(AMBER,∮3,TAPING)
410-6K2-436 2 *
D423,424 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 2 *
D425 941263100550P LED ( GREEN ) 410-CD6000-124A 1
D425 nsp LED HOLDER(LED3-1A-B,H=1.5mm,BLACK) 504-HDJ2000-097 1
D426,427 941176100170P
LED(RED,LTL1CHJEDNN-012A,∮3)
410-DJ5000-253T 2 *
D428,429 941176100180P
LED(YELLOW/GREEN,∮3,TAPING)
410-6K2-435 2 *
D430 941263004490P LED ( LTL-1CHY,YELLOW ) 410-CD6000-123 1
D430 nsp LED HOLDER(LED3-1A-B,H=1.5mm,BLACK) 504-HDJ2000-097 1
D431 941263004490P LED ( LTL-1CHY,YELLOW ) 410-CD6000-123 1
D431 nsp LED HOLDER(LED3-1A-B,H=1.5mm,BLACK) 504-HDJ2000-097 1
D432,433 nsp SENSOR(LTH-301-07) 417-HDJ2000-411 2
D434 941263004490P LED ( LTL-1CHY,YELLOW ) 410-CD6000-123 1
D434 nsp LED HOLDER(LED3-1A-B,H=1.5mm,BLACK) 504-HDJ2000-097 1
D435 941263004490P LED ( LTL-1CHY,YELLOW ) 410-CD6000-123 1
D435 nsp LED HOLDER(LED3-1A-B,H=1.5mm,BLACK) 504-HDJ2000-097 1
D436 941263004490P LED ( LTL-1CHY,YELLOW ) 410-CD6000-123 1
D436 nsp LED HOLDER(LED3-1A-B,H=1.5mm,BLACK) 504-HDJ2000-097 1
D437 941263100550P LED ( GREEN ) 410-CD6000-124A 1
D437 nsp LED HOLDER(LED3-1A-B,H=1.5mm,BLACK) 504-HDJ2000-097 1
D438 941263100550P LED ( GREEN ) 410-CD6000-124A 1
D438 nsp LED HOLDER(LED3-1A-B,H=1.5mm,BLACK) 504-HDJ2000-097 1
D439 941263100550P LED ( GREEN ) 410-CD6000-124A 1
D439 nsp LED HOLDER(LED3-1A-B,H=1.5mm,BLACK) 504-HDJ2000-097 1
D440 941263100530P LED (6224-10ID-A,RED ) 410-CD6000-122A 1
D440 nsp LED HOLDER(LED3-1A-B,H=1.5mm,BLACK) 504-HDJ2000-097 1
D441 941263100550P LED ( GREEN ) 410-CD6000-124A 1
D441 nsp LED HOLDER(LED3-1A-B,H=1.5mm,BLACK) 504-HDJ2000-097 1
D442 941263100550P LED ( GREEN ) 410-CD6000-124A 1
D442 nsp LED HOLDER(LED3-1A-B,H=1.5mm,BLACK) 504-HDJ2000-097 1
D443,444 nsp SENSOR(LTH-301-07) 417-HDJ2000-411 2
D445 941263100530P LED (6224-10ID-A,RED ) 410-CD6000-122A 1
D445 nsp LED HOLDER(LED3-1A-B,H=1.5mm,BLACK) 504-HDJ2000-097 1
D449-456 nsp SWITCHING DIODE(ISS355VM 1.7*1.25MM) 414-CD1000-075A
8
IC401 941236101640P IC(74HCT595) 417-6K2-1141 1
IC402 941239004980P IC(74HC4052D/74HC4052DT,SMD) 417-QSPAND-432 1
IC403 941236101650P IC(74HC14 SOP14 ST PB FREE) 417-CDN34-274 1 *
Q403-405 941214004530P CHIP TRANSISTOR(2SD1757KT146R,SMT3) 416-MC6000-374 3
Q406,407 941213500220P TRANSISTOR(TR DTC124EKAT146 SMT3) 416-CDN88-044 2
Q408-410 941214004530P CHIP TRANSISTOR(2SD1757KT146R,SMT3) 416-MC6000-374 3
Q411,412 941213500220P TRANSISTOR(TR DTC124EKAT146 SMT3) 416-CDN88-044 2
Q413,414 941214004530P CHIP TRANSISTOR(2SD1757KT146R,SMT3) 416-MC6000-374 2
RESISTOR GROUP
R400 nsp CHIP RESISTOR(100K OHM,1/10W,0603 ,J,TP) 412-CDVD2001-537 1
R412,413 nsp CHIP RESISTOR(220 OHM,1/10W,0603 ,J,TP 50V) 412-CDVD2001-521 2
R415,416 nsp CHIP RESISTOR(100 OHM,1/10W, 0603,J,TP) 412-CDVD2001-530 2
R417-419 nsp CHIP RESISTOR(4.7K OHM,1/10W, 0603,J,TP) 412-CDVD2001-523 3
R420-422 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 3
R424 nsp CHIP RESISTOR(56 OHM,1/10W,J,TP 0603,50V 412-I1-1252 1
R425 nsp CHIP RESISTOR(150 OHM,1/10W,0603,J,TP ) 412-CD900-795 1
R426,427 nsp CHIP RESISTOR(56 OHM,1/10W,J,TP 0603,50V 412-I1-1252 2
R428 nsp CHIP RESISTOR(150 OHM,1/10W,0603,J,TP ) 412-CD900-795 1
R429,430 nsp CHIP RESISTOR(56 OHM,1/10W,J,TP 0603,50V 412-I1-1252 2
R431 nsp CHIP RESISTOR(150 OHM,1/10W,0603,J,TP ) 412-CD900-795 1
R432,433 nsp CHIP RESISTOR(56 OHM,1/10W,J,TP 0603,50V 412-I1-1252 2
R434 nsp CHIP RESISTOR(150 OHM,1/10W,0603,J,TP ) 412-CD900-795 1
R435-437 nsp CHIP RESISTOR(56 OHM,1/10W,J,TP 0603,50V 412-I1-1252 3
R438 nsp CHIP RESISTOR(150 OHM,1/10W,0603,J,TP ) 412-CD900-795 1
R439,440 nsp CHIP RESISTOR(56 OHM,1/10W,J,TP 0603,50V 412-I1-1252 2
R441 nsp CHIP RESISTOR(10 OHM,1/10W,J,TP 0603,50V) 412-810-966 1
R442 nsp CHIP RESISTOR(2.7K OHM,1/10W,V,J,TP,50V) 412-007USB-677 1
R443,444 nsp CHIP RESISTOR(220 OHM,1/10W,0603 ,J,TP 50V) 412-CDVD2001-521 2
R445 nsp CHIP RESISTOR(2.7K OHM,1/10W,V,J,TP,50V) 412-007USB-677 1
R446 nsp CHIP RESISTOR(22K OHM,1/10W,0603,J,TP ) 412-007USB-704 1
R447 nsp CHIP RESISTOR(270 OHM,1/10W,0603,J,TP) 412-007USB-698 1
R448 nsp CHIP RESISTOR(22K OHM,1/10W,0603,J,TP ) 412-007USB-704 1
R449 nsp CHIP RESISTOR(270 OHM,1/10W,0603,J,TP) 412-007USB-698 1
R450-452 nsp CHIP RESISTOR(4.7K OHM,1/10W, 0603,J,TP) 412-CDVD2001-523 3
R453-456 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 4
R458-461 nsp CHIP RESISTOR(150 OHM,1/10W,0603,J,TP ) 412-CD900-795
4
R462-465 nsp CHIP RESISTOR(56 OHM,1/10W,J,TP 0603,50V 412-I1-1252 4
R466 nsp CHIP RESISTOR(150 OHM,1/10W,0603,J,TP ) 412-CD900-795 1
R467-469 nsp CHIP RESISTOR(56 OHM,1/10W,J,TP 0603,50V 412-I1-1252 3
R470,471 nsp CHIP RESISTOR(2.7K OHM,1/10W,V,J,TP,50V) 412-007USB-677 2
R472 nsp CHIP RESISTOR(22K OHM,1/10W,0603,J,TP ) 412-007USB-704 1
R473 nsp CHIP RESISTOR(270 OHM,1/10W,0603,J,TP) 412-007USB-698 1
R474 nsp CHIP RESISTOR(22K OHM,1/10W,0603,J,TP ) 412-007USB-704 1
R475 nsp CHIP RESISTOR(270 OHM,1/10W,0603,J,TP) 412-007USB-698 1
R476,477 nsp CHIP RESISTOR(4.7K OHM,1/10W, 0603,J,TP) 412-CDVD2001-523 2
R478 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ) 412-CDVD2001-534 1
R479 nsp CHIP RESISTOR(56 OHM,1/10W,J,TP 0603,50V 412-I1-1252 1
CAPACIITORS GROUP
