Denon MC6000MK2EM User Manual

IO
11
REF No. Part No. Part Name Remarks Q'ty New Ver
C686,687 nsp CHIP CAPACITOR(470pF/50V,J,0603 TAP,NPO) 413-007USB-786 2
C688,689 nsp CHIP CAPACITOR(120pF/50V,J,0603 TAP,NPO) 413-900-930 2
C690,691 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 2
C692-697 nsp CHIP CAPACITOR(150pF/50V,J,0603 TAP,NPO) 413-900-931 6
C698-701 nsp
ELEC. CAPACITOR(100uF/25V,M,105℃,TAPING)
413-SPPW3-238 4
C702,703 nsp
ELEC. CAPACITOR(470uF/10V,M, 105℃,TAPING)
413-HT8015-169 2
C704-709 nsp ELEC. CAPACITOR(220uF/25V,LOW ESR TYPE) 413-6K2-1296 6
C710,711 nsp CHIP CAPACITOR(1000pF/50V,K,0603 TAP,X7R) 413-DCM280-768 2
C712-717 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 6
C718,719 nsp CHIP CAPACITOR(470pF/50V,J,0603 TAP,NPO) 413-007USB-786 2
C721 nsp CHIP CAPACITOR(0.015uF/50V,M,0603 TAP,Y5V) 413-M207-1090 1
C722 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 1
C739 00D9587054907
ELEC. CAPACITOR(100uF/10V,M,105℃,TAPING)
413-HMA2200-5017 1
C750-752 00D9587054907
ELEC. CAPACITOR(100uF/10V,M,105℃,TAPING)
413-HMA2200-5017 3
C754-757 00D9587054907
ELEC. CAPACITOR(100uF/10V,M,105℃,TAPING)
413-HMA2200-5017 4
C758-760 nsp CHIP CAPACITOR(1uF/16V,Z,0603 TAP,Y5V) 413-007USB-797 3
C761-771 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 11
C773 nsp CHIP CAPACITOR(0.01uF/50V,J,0603 TAP,NPO) 413-DCM280-889 1
C774-784 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 11
C785-788 nsp CHIP CAPACITOR(1000pF/50V,K,0603 TAP,X7R) 413-DCM280-768 4
C789-801 nsp CHIP CAPACITOR(0.01uF/50V,J,0603 TAP,NPO) 413-DCM280-889 13
C804,805 nsp CHIP CAPACITOR(0.01uF/50V,J,0603 TAP,NPO) 413-DCM280-889 2
C806,807 nsp
ELEC. CAPACITOR(10uF/25V,M,105℃,TAPING)
413-SPPW3-235 2
C808 nsp
ELEC. CAPACITOR(47uF/25V,M,105℃,TAPING)
413-SPPW3-237 1
C809-815 nsp
ELEC. CAPACITOR(10uF/25V,M,105℃,TAPING)
413-SPPW3-235 7
C816 nsp
ELEC. CAPACITOR(47uF/25V,M,105℃,TAPING)
413-SPPW3-237 1
C817-819 nsp
ELEC. CAPACITOR(10uF/25V,M,105℃,TAPING)
413-SPPW3-235 3
C821 nsp
ELEC. CAPACITOR(47uF/25V,M,105℃,TAPING)
413-SPPW3-237 1
C823 nsp
ELEC. CAPACITOR(10uF/25V,M,105℃,TAPING)
413-SPPW3-235 1
C824-831 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 8
C834 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 1
C837-839 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 3
C840-845 nsp
ELEC. CAPACITOR(3.3uF/50V,M,105℃,TAPING)
413-HPR1-821 6
C847 nsp
ELEC. CAPACITOR(3.3uF/50V,M,105℃,TAPING)
413-HPR1-821 1
C849 nsp
ELEC. CAPACITOR(3.3uF/50V,M,105℃,TAPING)
413-HPR1-821 1
C851 nsp
ELEC. CAPACITOR(3.3uF/50V,M,105℃,TAPING)
413-HPR1-821 1
C852,853 nsp
ELEC. CAPACITOR(10uF/35V,TL M 105℃ 5*11)
413-45X-1244 2
C855 nsp
ELEC. CAPACITOR(10uF/35V,TL M 105℃ 5*11)
413-45X-1244 1
C856 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 1
C859 nsp CHIP CAPACITOR(1000pF/50V,K,0603 TAP,X7R) 413-DCM280-768 1
C860 nsp CHIP CAPACITOR(0.01uF/50V,J,0603 TAP,NPO) 413-DCM280-889 1
C861 nsp
CHIP CAPACITOR(1000pF/50V,K,0603 TAP,X7R)
413-DCM280-768
1
C862 nsp CHIP CAPACITOR(0.01uF/50V,J,0603 TAP,NPO) 413-DCM280-889 1
OTHER PARTS GROUP
B501 nsp FIXED PLATE 300-4500-2010A 1
K500 nsp GROUND PLATE 300-QFX19-811 1
K500 941643101350P 4P RCA JACK(RCA-413) 420-QMX1-094 1
K502 nsp GROUND PLATE 300-SPIN2T-1748 1
K502 941643101380P 2P RCA JACK(RCA-213) 420-MX1000-172A 1
K503 nsp GROUND PLATE 300-DJA-1702 1
K503 941644101790S 2P RCA JACK(RJ-1078-10-0300A) 420-RCC955A-073 1
K504,505 941643004890P XLR JACK(94M008P2-G-H,4P) 420-MC6000-353 2
K506 nsp GROUND PLATE 300-SPIN2T-1748 1
K506 941643101380P 2P RCA JACK(RCA-213) 420-MX1000-172A 1
K507 941643004920P MIC JACK(03M8007P-H) 420-MH2-223 1
K509 941445005000P JACK GROUND PLATE 300-300-1171 1
K509 941643101370P 3P PHONE JACK(6.4,JY-6313-02-030) 420-HMJ1001-5034 1
K510 941445005000P JACK GROUND PLATE 300-300-1171 1
K510 941643101370P 3P PHONE JACK(6.4,JY-6313-02-030) 420-HMJ1001-5034 1
K511 941445005000P JACK GROUND PLATE 300-300-1171 1
K511 941643101370P 3P PHONE JACK(6.4,JY-6313-02-030) 420-HMJ1001-5034 1
L40 nsp INDUCTOR(220OHM,100MHZ,N2012ZP221T20) 415-4003-343 1
L41-43 nsp BEAD CORE(A70512003, T-26mm) 415-HV3500K-090 3
L44 nsp INDUCTANCE(15uH) 415-IM-302 1
L750-754 nsp CHIP BEAD(FBMA-11-201209-121T,120Ω/100M) 415-IS201-382 5
L755 nsp INDUCTOR(220OHM,100MHZ,N2012ZP221T20) 415-4003-343 1
L757-761 nsp INDUCTOR(220OHM,100MHZ,N2012ZP221T20) 415-4003-343 5
L763 nsp INDUCTOR(220OHM,100MHZ,N2012ZP221T20) 415-4003-343 1
L764 nsp CHIP BEAD(FBMA-11-160808-121A10T,120Ω/100MHz) 415-COMBO-418 1
L776 nsp INDUCTOR(220OHM,100MHZ,N2012ZP221T20) 415-4003-343 1
N105 941644101920P 20P 1.0 FFC SOCKET 404-DJM250-3613 1 *
N1TOCB1PCB\\W1
941644000540S 4P SOCKET(CKM2501WV-4P 180°WHITE) 404-HV3500K-629A 1
N380TOFRONT\\PC
nsp 4P SOCKET(CKM2501WR-4P 90°WHITE) 404-QMX2-606A 1
N801 941644101910P 10P 1.0 FFC SOCKET(1.0D-10PBS,90°) 404-PDJ22-3567 1 *
N802TOMAIN\\PCB
nsp 6P CONNECTOR WIRE(L=140mm,UL2468#26) 404-M5-1507 1
S500-502 00D9587015409 SLIDE SW(SSSF122NA1-HF,6PIN) 403-QMX1-060 3
