Denon MC6000MK2EM - Front and Cross Fader Board Components

FRONT
12
FRONT PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed b
olumn Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
IC380,381 941239004980P IC(74HC4052D/74HC4052DT,SMD) 417-QSPAND-432 2
RESISTOR GROUP
R380 nsp CHIP RESISTOR(10 OHM,1/10W,J,TP 0603,50V) 412-810-966 1
R381-384 nsp CHIP RESISTOR(3.3K OHM,1/10W, 0603,J,TP) 412-007USB-699 4
R385,386 nsp CHIP RESISTOR(7.5K OHM,1/10W,J,TP 0603) 412-G9900-1196 2
R387 nsp CHIP RESISTOR(10 OHM,1/10W,J,TP 0603,50V) 412-810-966 1
R388,389 nsp CHIP RESISTOR(7.5K OHM,1/10W,J,TP 0603) 412-G9900-1196 2
R390-393 nsp CHIP RESISTOR(3.3K OHM,1/10W, 0603,J,TP) 412-007USB-699 4
R394 nsp CHIP RESISTOR(100K OHM,1/10W,0603 ,J,TP) 412-CDVD2001-537 1
R395-398 nsp CHIP RESISTOR(3.3K OHM,1/10W, 0603,J,TP) 412-007USB-699 4
VR380 nsp VR FIXED PLATE 300-6000-1874 1
VR380 941671005040P ROTARY VR(RD901F-20B3-20F-B20K-00D17A) 418-MC6000-634 1
VR381 nsp VR FIXED PLATE 300-6000-1874 1
VR381 941671005050P ROTARY V(RD901F-20B3-20F-B20K-0CD16A) 418-MC6000-635 1
VR382-385 941671100520P ROTARY VR(20KB,RD901F-20-13F-B20K-0CD38A) 418-6K2-719 4 *
VR386 941671100510P ROTARY VR(20KB,RD901F-20-13F-B20K-00D38A) 418-6K2-718 1 *
VR389,390 941671100520P ROTARY VR(20KB,RD901F-20-13F-B20K-0CD38A) 418-6K2-719 2 *
VR391 941671100510P ROTARY VR(20KB,RD901F-20-13F-B20K-00D38A) 418-6K2-718 1 *
CAPACIITORS GROUP
C380,381 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 2
C382,383 nsp CHIP CAPACITOR(330pF/50V,J,0603 TAP,NPO) 413-900-925 2
C384,385 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 2
C386,387 941134001550S
ELEC. CAPACITOR(10uF/16V,M,105℃,TAPING)
413-DV300-5155 2
C390 nsp CHIP CAPACITOR(0.1uF/50V,Z,0603 TAP,Y5V) 413-DCM280-773 1
OTHER PARTS GROUP
CN104 941644101430P 14P 1.0 FFC SOCKET(1.0D-14PBS) 404-3000-3620 1
JK380 941445005000P JACK GROUND PLATE 300-300-1171 1
JK380 941643101370P 3P PHONE JACK(6.4,JY-6313-02-030) 420-HMJ1001-5034 1
L41 nsp FIXED PLATE 300-4500-2010A 1
L41 nsp FIXED PLATE 300-4500-2010A 1
SW380-383 941664005030P SLIDE SW(SSSF113NA3-HF,L=6) 403-IM-314 4
SW384 00D9587015409 SLIDE SW(SSSF122NA1-HF,6PIN) 403-QMX1-060 1
W380 nsp 4P 2.5 CONNECTOR WIRE(L=100mm) 404-6K2-3826 1
nsp BRACKET(L TYPE) 300-HDJ7000-472 1
nsp SCREW(3*5 P=0.5) 602-B300-041
1
