15
(5) DisconnecttheFFCcable.
7. SPK UNIT
8. TRANS
9. GUIDE UNIT
FFC cable
Direction of photograph: B
Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofeachPCBincludedinREARPANELSUBASSY.
Proceeding : TOP CABINET
REAR PANEL SUB ASSY
SPK UNIT
Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofSPKUNIT.
Proceeding : TOP CABINET
REAR PANEL SUB ASSY
SPK UNIT
TRANS
Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofTRANS.
Proceeding : TOP CABINET
REAR PANEL SUB ASSY
SPK UNIT
TRANS
GUIDE UNIT
Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofGUIDEUNIT.
