PARTS LIST OF EXPLODED VIEW
zParts for which "nsp" is indicated on this table cannot be supplied.
z
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
zPart indicated with the mark " ★ " is not illustrated in the exploded view.
zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model EK : U.K. model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
C2 nsp MCU_CD_DSP PCB ASSY E3 COP12284E 1 *
C2 nsp MCU_CD_DSP PCB ASSY EK,E2 COP12284B 1 *
C8' nsp INPUT PCB ASS'Y E3 COP12285E 1 *
C8' nsp INPUT PCB ASS'Y EK/E2 COP12285B 1 *
C8 - INPUT PCB
C13 - REGULATOR PCB
C14 - DCDC PCB
C1' nsp MAIN PCB ASS'Y E3 COP12286E 1 *
C1' nsp MAIN PCB ASS'Y EK,E2 COP12286B 1 *
C1 - FRONT PCB
C4 - AMP PCB
C5 - GUIDE PCB
C6 - SUB TRANS PCB
C7 - SPK PCB
z
C3 00D2033905015 INLET E3 CJJ8A013Z 1
z
C3 943641009280S INLET EK,E2,JP CJJ8A012Z 1
C9 943189009060D DAB MODULE EK CNVFS2027B 1 *
C10 943302009630S CD MECHANISM ASS'Y CDJL2130BZ 1 *
z
C11 943101009240S POWER TRANS E3 CLT5P047ZU 1
z
C11 943101009220S POWER TRANS EK,E2 CLT5P047ZE 1 *
C12 943183009270S TUNER MODULE E3 CNVMT004MS0-80 1 *
C12 943183009250S TUNER MODULE EK,E2 CNVMT104MS1-80 1 *
M1 943412009020D VOLUME KNOB ASSY BK CGK1A162ZA 1
*
M1 943412009010D VOLUME KNOB ASSY SP CGK1A162YA 1 *
M2 00D1310158049 BADGE , DENON BK CGB1A140U 1
M2 00D1310158052 BADGE , DENON SP CGB1A140T 1
M3 943402009750D FRONT PANEL (K) E3 CKM2A196WC45 1 *
M3 943402009770D FRONT PANEL (BKEK) BKEK CKM2A196YC45 1 *
M3 943402009780D FRONT PANEL (SPEK) SPEK CKM2A196YC62 1 *
M3 943402009790D FRONT PANEL (BKE2) BKE2 CKM2A196ZC45 1 *
M3 943402009800D FRONT PANEL (SPE2) SPE2 CKM2A196ZC62 1 *
M4 943411000460D POWER KNOB ASSY BK CGX1A353XA 1
M4 00D9430211100 POWER KNOB ASSY SP CGX1A353YA 1
M5 nsp FIP BRACKET CMD1A468 2
M6 943403009410D CABINET, TOP BK CKC2A186S56 1 *
M6 943403009420D CABINET, TOP SP CKC2A186S55 1 *
M7 nsp BOTTOM, CHASSIS CUA3A286 9
M8 nsp HT BRACKET CMD1A672 9
M9 nsp HEAT SINK CMY2A301 9
M10 nsp PANEL, REAR E3 CKF1A435Y 1 *
M10 nsp PANEL, REAR EK CKF2A435Z 1 *
M10 nsp PANEL, REAR E2 CKF2A435Z 1 *
M11 nsp DAB NUT EK CNE1A009 1
M12 nsp HEAT SINK CMY1A305 1
s
s
s
s
s
s
s
Ref. No. Part No. Part Name Remarks Q'ty New
M13 nsp PCB BRACKET CMD1A569 7
M14 nsp PCB BRACKET CMD1A387 1
M15 nsp EARTH PLATE CMC1A350 1
M16 nsp USB EARTH PLATE CMC1A351 1
M17 nsp TRANS BRACKET CMD1A686 1
P1 943443009050D INNER PANEL ASS'Y BK CGW2A456YA 1 *
P1 943443009040D INNER PANEL ASS'Y SP CGW2A456ZA 1 *
P2 943416009030D FL WINDOW CGU1A418Y 1
P3 943481000370D LENS CGL1A230A14 1
P4 nsp CUSHION , FOOT CHG1A360 4
P5 00D9430094506 FOOT CKL1A189 4
P6 nsp MECHA SUPPORT CMH1A287 2
P7 nsp SUPPORT EK CNW1A038 1
P8 nsp INSULATOR CMX1A280 1
P9 943415000380D DOOR BK CGR1A450B28 1
P9 943415000390D DOOR SP CGR1A450RGG45 1
BN25 nsp
6P WIRE ASS'Y
(6P, 100MM, 2.0MM PITCH)
CWZRCDM37BN25 1
BN26 nsp
5P WIRE ASS'Y
(5P, 100MM, 2.0MM PITCH)
CWZRCDM37BN26 1
WN24 943606001050S
CABLE , CARD
(16P, 200MM, 1.0MM PITCH)
CWC4F1A16A150AZ 1
WN11 943606001010S CABLE , CARD(15P, 120mm) CWC4F4A15A120BZ 1
WN12 943606001040S CABLE , CARD(9P, 180MM 1.0MM) CWC4F4A09A180B 1
WN21 943606009430S CARD, CABLE (11P,1.25,120mm,Atype) CWC4F4A11B120BZ 1 *
WN81 943606001020S CABLE , CARD(19P, 150mm) CWC4F4A19A150BZ
1
SCREWS
S1 nsp SCREW CTB4+8FR 4
S2 nsp SCREW CTW3+18JR 2
S3 nsp SCREW CTB3+8JFZR 19
S4 nsp SCREW CTB3+10JFZR 22
S5 nsp DOT SCREW BK CTBD3+8JFZR 6
S5 nsp DOT SCREW SP CTBD3+8JFN 6
S6 nsp SCREW BK CTWD4+6FFZR 2
S6 nsp SCREW SP CTWD4+6FFN 2
S7 nsp SCREW CTB3+6FFZR 1
S8 nsp SCREW CTS3+8JFZR 4
61
