85
PARTS LIST OF P.C.B. UNIT
zParts for which "nsp" is indicated on this table cannot be supplied.
zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model EK : U.K. model
BK : Black model SP : Premium Silver model
MCU_CD_DSP PCB ASSY
d
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC11 943243009090D IC U-COM RCD-M38(TMPM330FYFG,TOSHIBA) E3,E2 CVIANAM1513CR *
IC11 943243009100D IC U-COM RCD-M38(TMPM330FYFG,TOSHIBA) EK CVIANAM1512CR *
IC12 943243009110D IC EEPROM(16K,2.5V~5.5V,SOP-8P) CVIM24C16WMN6TP *
IC13 943234009290S IC RESET 2.4V (200ms,C-MOS,SOT23-5P) CVIS80124CLMCJIJT2
IC14 00D9430183608 IC TC74HCU04AFNG HVI74HCU04AFNG
IC15 90M-HC700520R IC K74VHC04M HVI74VHC04MX
IC16 943245006980S IC CD DSP (SERVO,AMPLIFIER,DSP,LQFP-80P) CVITC94A92FG
IC17 90M-HC900040R IC REGULATOR (+9V,DPAK) CVIKIA7809AF
IC18 00D9430183608 IC TC74HCU04AFNG HVI74HCU04AFNG
IC31 943239006900S
IC 5-CH MOTOR DRIVE IC (WITH REG,SSOP-28P)
CVIIP4001CRLTF
IC41 943243009080D IC USB DECODER FLASH RCD-M38 CVIANAM1511CR
IC42 236710076509S
IC IPOD AUTHENTICATION CHIP FROM
MARANTZ
CVI236710076509S-DM
IC51 00D9430209701 IC KIA1117S/F33 REGULATOR(SOT-223) CVIKIA1117S33
IC52 90M-HC900160R IC LM1117S15 REGULATOR(SOT-223) CVIKIA1117S15
IC71 943239007340S IC DCDC CONVERTER (3.5A) CVISI8005QTL
D101,102 90M-HD201800R DIODE 1SS355 HVD1SS355T
D103 90M-HD201820R DIODE RB160L-60TE25 HVDRB160L60TE25
D104,105 90M-HD201800R DIODE 1SS355 HVD1SS355T
D106,107 90M-HD201820R DIODE RB160L-60TE25 HVDRB160L60TE25
D108 90M-HD201800R DIODE 1SS355 HVD1SS355T
D201 90M-HD201800R DIODE 1SS355 HVD1SS355T
D401 00D9430041106 DIODE RB160L-60TE25 HVDRB160L60TE25
D501,502 90M-HD201800R DIODE 1SS355 HVD1SS355T
D701 943204006840S DIODE SCHOTTKY 40V3A DO-214AC CVDSS34SR
Q101 00D9430037903 CHIP TR KRC102S HVTKRC102S
Q102-108 00D9430038009 CHIP TR KRA102S HVTKRA102S
Q109 00D9430037903 CHIP TR KRC102S HVTKRC102S
Q110 00D9430038009 CHIP TR KRA102S HVTKRA102S
Q111 00D9430037903 CHIP TR KRC102S HVTKRC102S
Q112 00D9430038009 CHIP TR KRA102S HVTKRA102S
Q113,114 00D9430037903 CHIP TR KRC102S HVTKRC102S
Q201 00D9430058908 CHIP TR KTA1504S Y RTK HVTKTA1504SYRTK
Q402-404 00D9430037903 CHIP TR KRC102S HVTKRC102S
Q909 00D9430037903 CHIP TR KRC102S HVTKRC102S
CAPACITORS GROUP
C101-106 nsp CHIP CAP 0.1uF 50V CCUS1H104KC
C107 nsp ELECT CAP HCEC0JRV102T
C108,109 nsp CHIP CAP 12pF 50V CCUS1H120JA
C110 nsp CHIP CAP 0.1uF 50V CCUS1H104KC
s
d
d
d
d
d
To Next Page
