TMP92FD28FG Terminal Function
Pin No Port Name Port Name I/O
Status
Note
Pull-U/D init. stby Act.
1 /RESET RESET I
2 PC0 N.C I Open
3 PC1 N.C I Open
4 PC2 N.C I Open
5 PC3 USB-REQ I PD - - L STREQ to Oasis(IC16)
6 DVCC3B VDD3.3V P
7 PC6 N.C O L Open
8 PC7 N.C O L Open
9 /PWE N.C O Open
10 DVSS1B DVSS1B G
11 DVCC1B DVCC1B P
12 RVOUT1 RVOUT1 O
13 RVIN RVIN P Flash version is a terminal Power supply 3.3V
14 RVIN RVIN P Flash version is a terminal Power supply 3.3V
15 RVOUT2 RVOUT2 G
16 DVCC1A DVCC1A P
17 DVSS1A DVSS1A G
18 P00 N.C O L Open
19 P01 N.C O L Open
20 P02 N.C O L Open
21 P03 MCU_RESET O L L H for HOST MCU writing
22 P04 MCU_BOOT O L L H for HOST MCU writing
23 P05 UPDATE_LED O L L H when update, LED blink
24 P06 PWR ON_BOL O L L H when update, control power on
25 P07 N.C O L Open
26 DVSS3A DVSS3A G
27 DVCC3A VDD3.3V P
28 P10 MODEL OPTION O PU/PD L L H or L RCD-M38:"LOW" / RCD-M38DAB:"HIGH"
29 P11 MODEL OPTION O L L L RCD-M38"LOW" / MC-R503 "HIGH"
30 P12 N.C O L Open
31 P13 CP-RESET O H L L to Apple Chip (WWI) IC42(MFI341S2164)
32 P14 N.C O L Open
33 P15 N.C O L Open
34 P16 N.C O L Open
35 P17 N.C O L Open
36 P40 N.C O L Open
37 P41 N.C O L Open
38 P42 N.C O L Open
39 P43 N.C O L Open
40 P44 N.C O L Open
41 P45 N.C O L Open
42 P46 N.C O L Open
43 P47 N.C O L Open
44 DVSS3A DVSS3A G
45 DVCC3A VDD3.3V P
46 P50 N.C O L Open
47 P51 N.C O L Open
48 P52 N.C O L Open
49 P53 N.C O L Open
50 P54 N.C O L Open
51 P55 N.C O L Open
52 P56 N.C O L Open
53 P57 N.C O L Open
54 P60 N.C O L Open
55 P61 N.C O L Open
56 P62 N.C O L Open
57 P63 CD_BUS2 I - - H/L to Oasis (IC16)
58 P64 CD_BUS3 O L L H/L to Oasis (IC16)
59 P65 CD_BUCK O L L H/L to Oasis (IC16)
60 P66 CD-CCE O L L H/L to Oasis (IC16)
61 P67 DSP-RESET O H H L to Oasis (IC16)
62 DVSS3A GND G
63 DVCC3A VDD3.3V P
64 P70 N.C O L Open
