Denon RCD-M38DAB Service Manual

88
Ref. No. Part No. Part Name Remarks Q'ty New
C715 nsp CHIP CAP 0.1uF 50V CCUS1H104KC
C716 nsp CHIP CAP 0.01uF 50V CCUS1H103KC
OTHERS PARTS GROUP
BN12 nsp 2P SHEILD WIRE ASS'Y (200MM 2MM PITCH) CWZRCDM37BN12
CN22,23 nsp WAFER (CD MECHA) CJP06HA37ZM
CN25 nsp WAFER SMD (2MM PITCH) CJP06GA208ZY
CN26 nsp WAFER SMD (2MM PITCH) CJP05GA208ZY
CN71 nsp WAFER SMD (2MM PITCH) CJP05GA208ZY
CN83 nsp WAFER SMD (2MM PITCH) CJP05GA208ZY
CN96 nsp WAFER SMD (2MM PITCH) CJP05GA208ZY
CN98 nsp WAFER SMD (2MM PITCH) CJP09GA208ZY
F401 943661006910S POLY SWITCH (1.6A 8V) CBA5H1600PSUYT
L101 nsp CHIP FERRITE BEAD(60ohm 4516) CLZ9Z014Z
L201 90M-LU000220R CHIP INDUCTOR 10UH (3225 PKG) HLQ10E100KRZ
L301 nsp CHIP FERRITE BEAD(220ohm 2012) CLZ9R006Z
L401 nsp CHIP FERRITE BEAD(60ohm 4516) CLZ9Z014Z
L501 nsp CHIP FERRITE BEAD(60ohm 4516) CLZ9Z014Z
L701 nsp POWER COIL (22UH/3A) CLQ13E220MRZ
L702 nsp POWER COIL (47UH/3A) CLQ13E470MRZ
RN11 90M-BW000410R CHIP RES 10K OHM 1608 X 4 CRJ104DJ103T
WN11 nsp WAFER CARD CABLE SMD CJP15GA193ZY
WN12 nsp WAFER CARD CABLE SMD CJP09GA193ZY
WN21 nsp WAFER (11P ST 1.25MM) CJP11GA115ZY
WN24 nsp WAFER CARD CABLE SMD CJP16GA193ZY
WN81 nsp WAFER CARD CABLE CJP19GA193ZY
X101 943141009130D CRYSTAL 10MHz 12pF COX10000E120S *
X102 90M-JX001280R CRYSTAL 32.768KHz 12pF 20PPM HOX00032K120I
X201 943141001190S CRYSTAL 16.9344MHZ 12pF 25PPM COX16934E120S
X401 943141001200S CRYSTAL 09.000MHz 15pF 25PPM COX09000E150S
nsp IC HEAT SINK CMY1A305
