Denon RCD-M38DAB Service Manual

90
Ref. No. Part No. Part Name Remarks Q'ty New
C165 nsp ELECT CAP 100UF 6.3V EK CCEA0JKS101T
C166 nsp CHIP CAP 0.01uF 50V EK CCUS1H103KC
C167 nsp ELECT CAP 47UF 6.3V EK CCEA0JKS470T
C168 nsp CHIP CAP 0.01uF 50V EK CCUS1H103KC
C169 nsp ELECT CAP 47UF 6.3V EK CCEA0JKS470T
C170,171 nsp CHIP CAP 0.1uF 50V EK CCUS1H104KC
C172,173 nsp ELECT CAP 10UF 50V CCEA1HKS100T
C174 nsp CHIP CAP 0.1uF 50V CCUS1H104KC
C175 nsp CHIP CAP 390PF 50V CCUS1H391JA
C176 nsp CHIP CAP 220pF 50V CCUS1H221JA
C177,178 nsp CHIP CAP 1200PF 50V CCUS1H122KC
C179 nsp CHIP CAP 220pF 50V CCUS1H221JA
C180 nsp CHIP CAP 0.1uF 50V CCUS1H104KC
C181 nsp ELECT CAP 220UF 50V CCEA1HRFO221E
C182 nsp CHIP CAP 0.1uF 50V CCUS1H104KC
C183 nsp CHIP CAP 390PF 50V CCUS1H391JA
C192-195 nsp CAP, ELECT 330UF 10V EK CCUS1H104KC
C196 nsp ELECT CAP 330UF 10V EK CCEA1AH331T
C197 nsp CHIP CAP 0.1uF 50V CCUS1H104KC
C198,199 nsp CERAMIC CAP 1200PF 50V CCKT1H122KB
C401,402 nsp ELECT CAP 10uF 50V CCEA1HH100T
C403-406 nsp CHIP CAP 0.1uF 50V CCUS1H104KC
C407,408 nsp ELECT CAP 4.7UF 50V CCEA1HKS4R7T
C409 nsp CHIP CAP 0.01uF 50V CCUS1H103KC
C410 nsp CHIP CAP 0.01uF 50V CCUS1H103KC
C910 nsp CHIP CAP 0.1uF 50V CCUS1H104KC
C913-919 nsp CHIP CAP 0.1uF 50V CCUS1H104KC
OTHERS PARTS GROUP
BK11 nsp PCB BRACKET CMD1A387
BK12 nsp PCB BRACKET CMD1A569
BN73 nsp WIRE ASS'Y CWB2B905100EN
CN11 nsp WAFER 30PIN EK CJP30GA221ZB
CN12 nsp WAFER 2PIN CJP02GA19ZY
CN72 nsp WAFER STRAIGHT 9PIN CJP09GA19ZY
JK11 90M-YT004010R TERMINAL IN/OUT CJJ4R019W
JK13 90M-YT004860R STEREO JACK CJJ2D008Z
L101 nsp CHIP BEAD EK HLZ9Z008Z
L103 nsp COIL AXAIL HLQ02C220KT
L104 nsp FERRITE CHIP BEAD(60ohm 4516) CLZ9Z014Z
L105,106 nsp FERRITE CHIP BEAD(60ohm 4516) EK CLZ9Z014Z
WF11 nsp WAFER CARD CABLE CJP15GA117ZY
WF12 nsp WAFER CJP09GA117ZY
