Denon RCD-M38DAB Service Manual

92
Ref. No. Part No. Part Name Remarks Q'ty New
Q712,713 00D9430154200 TR KRA102M HVTKRA102MT
Q714 00D9430107804 TR KRC102M HVTKRC102MT
Q805,806 00D9430037903 TR KRC102S HVTKRC102S
Q809,810 90M-BA001500R TR KRC111M HVTKRC111MT
Q811 90M-HX800090R TR KRC111S HVTKRC111S
Q901 00D9430154200 TR KRA102M HVTKRA102MT
Q902,903 90M-BA001460R TR KRC107M HVTKRC107MT
Q906-908 00D9430107804 TR KRC102M HVTKRC102MT
Q910 00D9430107804 TR KRC102M HVTKRC102MT
Q911 90M-BA001460R TR KRC107M HVTKRC107MT
Q912 00D9430072609 TR KTC3199Y HVTKTC3199YT
RESISTORS GROUP
R704,705 nsp RES, METAL(OXIDE)FILM,5% KRG1SANJ4R7RT
R706,707 nsp RES CARBON CRD25FJ4R7T
R708,709 nsp RES CEMENT CRF5EKR22
R742 943129001240S RES FUSIBLE CRQ14AJ101T
R744,745 nsp RES METAL OXIDE FILM(1W, 330) CRG1SANJ331RT
R746 943129001240S RES FUSIBLE CRQ14AJ101T
R818 nsp WIRE COPPER C3A206
R821 nsp RES CARBON CRD20TJ122T
CAPACITORS GROUP
C702 nsp ELECT CAP 100UF 63V CCEA1JH101E
C703,704 nsp ELECT CAP 10uF 50V CCEA1HH100T
C706,707 943139001210S METALLIZED FLIM CAP 0.22UF 100V CCME2A224JXT
C708,709 943133001380S METALLIZED FILM CAP CCME2A473JXT
C710 nsp ELECT CAP 470uF 10V CCEA1AH471T
C711,712 nsp CERAMIC CAP 0.1UF 50V CCBS1H104ZFT
C713 nsp ELECT CAP 47uF 25V CCEA1EH470T
C714,715 nsp CERAMIC CAP 0.01UF 50V CCBS1H103ZFT
C716,717 nsp ELECT CAP 4.7uF 50V CCEA1HH4R7T
C718,719 nsp CERAMIC CAP 470PF 50V CCKT1H471KB
C720 nsp ELECT CAP 47UF 50V CCEA1HRFO470T
C722 nsp CERAMIC CAP 5pF 50V CC CCCT1H050CC
C724 nsp ELECT CAP 47UF 50V CCEA1HRFO470T
C726 nsp ELECT CAP 10uF 63V CCEA1JRFO100T
C727 nsp ELECT CAP 100uF 50V CCEA1HRJ3101T
C728 nsp CERAMIC CAP 1000PF 50V CCBS1H102KBT
C734 nsp CERAMIC CAP 0.1UF 50V CCBS1H104ZFT
C735,736 nsp MYLAR CAP 6800pF 50V J HCQI1H682JZT
C737,738 00D9430189505 METALLIZED CAP 0.1uF 100V J CCME2A104JXT
C739,740 nsp CERAMIC CAP 0.01UF 100V CCME2A103JXT
C741 90M-OF100490R METALLIZED CAP 0.1uF 250V J KCME2E104JP04T
C742,743 943134001270S ELECT CAP 4700UF 35V CCEA1VRO472E
C744,745 nsp CERAMIC CAP 0.01UF 50V CCBS1H103ZFT
C746,747 nsp ELECT CAP 47UF 50V CCEA1HRFO470T
C748 nsp CERAMIC CAP 5pF 50V CC CCCT1H050CC
C749,750 nsp ELECT CAP 10uF 63V CCEA1JRFO100T
C751 nsp ELECT CAP CCEA1HH221E
C753-757 nsp CERAMIC CAP 0.1UF 50V CCBS1H104ZFT
