97
S-101
DSW-S101 PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model
E2 : Europe model
Ref. No. nsp Part No. Part Name Remarks Q'ty New
1A nsp 00D 101 2659 008 DSWS101 CABINET ASSY 1 *
1 nsp 00D 949 0057 101 BOX ASSY 1
2 - DUCT 2
3 - DUCT 1
4 00D 949 0060 800 CR200034-01 SP UNIT 1
5 00D 949 0058 906 +B 4X30 TAPPING SCREW 8
6 nsp 00D 949 0058 003 FOOT ASSY 4
7 00D 949 0059 002 +B 5X30 TAPPING SCREW 4
8 - FOOT 4
9 nsp 00D 949 0058 508 CORD ASSY 1
★ 10
nsp 00D 949 0056 908 PACKING 1
11 nsp 00D 1U- 3682 D SMPS UNIT ASS'Y E3 1 *
11 nsp 00D 1U- 3682 E SMPS UNIT ASS'Y E2 1 *
12A nsp 00D 1U- 3683 D AMP UNIT ASS'Y 1 *
12 - AMP UNIT
13 - IN/OUT UNIT
14 - TERMINAL UNIT
21 nsp 00D 105 1647 204 REAR PANEL(E3) E3 1 *
21 nsp 00D 105 1647 217 REAR PANEL(E2) E2 1 *
22 nsp 00D 412 5237 107 MAIN BRACKET 1 *
23 nsp 00D 443 9015 002 P.W. SPACER 2
24 - HEAT SINK 1
25 nsp 00D 415 0968 001 SPACER (CPV-0.5) 3 *
26 nsp 00D 445 0048 016 CORD HOLDER (L50) 1
27 nsp 00D 414 1030 003 SHIELD COVER 1
28 nsp 00D 414 1037 006 SHIELD COVER (AMP) 1 *
! 29 00D 203 3996 008 AC INLET (2P) 1
30 nsp 00D 412 5238 009 D-SUB BRACKET 1
31 - HEXAGON_HEAD_SCREW 2
32 nsp 00D 103 1816 107 TERNINAL COVER 1 *
33 00D 445 0127 005 CORD BUSH (KF-41) 1
34 00D 445 0056 008 CORD BUSH 1
35 00D 445 0129 003 CORD BUSH (KR-61) 1 *
36 00D 342 0027 000 FERRITE CORE 1
★ 41
nsp 00D 461 1238 063 PEF SHEET(15X30) 1 *
★ 42
nsp 00D 461 1238 005 PEF SHEET(7X70) 2 *
★ 43
nsp 00D 461 1238 018 PEF SHEET(7X155) 2 *
★ 44
nsp 00D 461 1238 021 PEF SHEET(10X182) 2 *
★ 45
nsp 00D 461 1238 034 PEF SHEET(10X280) 2 *
★ 46
nsp 00D 513 4071 104 RATING (DSW101E3) E3 1 *
★ 47
nsp 00D 513 4072 103 RATING (DSWS101E2) E2 1 *
