125
S-302
PARTS LIST OF PACKING & ACCESSORIES
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model JP : Japan model
Ref. No. Part No. Part Name Remarks Q'ty New
1 00D 501 2372 035 MASTER CARTON for E2 1 *
1 00D 501 2372 048 MASTER CARTON for E3 1 *
1 00D 501 2372 051 MASTER CARTON for JP 1 *
2 00D 502 1143 103 TOP SPACER 1*
3 00D 505 0312 057 CABINET COVER 1 *
4 00D 503 1550 100 CUSHION (L) 1*
5 00D 503 1551 109 CUSHION (R) 1*
6 00D 505 0312 060 CABINET COVER 1
7 00D 949 0069 006 CUSHION DSW(BOTTOM) 1 *
8 00D 949 0069 200 CUSHION DSW(UP) 1 *
9 00D 949 0069 103 CUSHION SC(BOTTOM) 1 *
10 00D 949 0069 006 CUSHION SC(UP) 1 *
11 00D 104 0348 019 SP STAND (EASY) 2 *
12 00D 461 1236 007 PORON (HH48 F10 T1) 4
13 00D 441 2002 003 WALL MOUNTER 2
14 00D 461 1236 007 PORON (HH48 F10 T1) 8
15 00D 505 0367 015 ENVELOPE for E2 1
15 00D 505 0038 030 POLY COVER(E3/JP) for E3, JP 1
16 00D 511 4621 105 INST.MANUAL(302E2) for E2 1 *
16 00D 511 4622 104 INST.MANUAL(302E3) for E3 1 *
16 00D 511 4623 006 INST.MANUAL(302J) for JP 1 *
17 nsp S.S.LIST(EX) for E3, E2 1
17 00D 515 0918 607 SERVICE STATION LIST for JP 1
18 00D 399 1101 002 REMOCON(RC1072) 1 *
19 nsp POLY COVER 1
20 nsp POLY COVER 1
21 nsp BATTERY (SUM-3) ASS 1
22 00D 203 0380 002 1P PIN CORD (VIDEO) 1
23 00D 231 1152 001 AM LOOP ANTENNA(S) 1
24 00D 395 0026 005 FM ANT. WIRE for E2 1
24 00D 395 0028 003 FM ANT ASS Y(F/WELT) for E3, JP 1
25 00D 461 1237 006 PORON (HH48 F6 T1) 1
26 00D 505 0343 000 ENVELOPE 1
27 0RD 471 3508 028 5X14 CBS-B 4
28 00D 395 0034 000 WLAN ANNTENA 1 *
29 00D 203 2444 001 SP CABLE ASSY(AWG22) 1
30 00D 204 6794 006 25P D-SUB CABLE 1
31 00D 511 4624 005 SETUP GUIDE 1*
★ 32
nsp WARRANTY (HOME) for E3 1
★ 33
00D 517 1505 028 UPC LABEL for E3 1 *
★ 33
nsp E2 POS LABEL for E2 2 *
★ 33
00D 517 1506 014 POS LABEL for JP 1 *
★ 34
00D 513 3880 008 DATE LABEL for JP 1
★ 35
nsp CONT.CARD(L)SUB ASSY for E3, E2 1
★ 36
nsp GUARANTEE(S)SUB ASSY for JP 1
