11
13 (39*)
26 (78*)
39 (117*)
52 (156*)
5
10
15
20
65 (195*)
78 (234*)
91 (273*
104 (312*)
25
30
35
40
117 (351*)
130 (390*)
45
50
m³
to protect
Seconds
of emission
m³
to protect
m³
to protect
Seconds
of emission
Seconds
of emission
SHOOTING TABLE Density® Basic (max 50 sec.)
* Industrial standard as from other manufacturers
The value in the first column indicates the volume of the room to be protected, with respective seconds of emission
reported in the second column. The value in m³ varies depending on the density to be obtained. With the suggested
value it is possible to get the maximum density recommended to ensure the absence of any residual. In places where
a little residual causes no problems, it is possible to increase the shooting time. Please note that the more fog
released, the more the time required to recover visibility. High levels of fog, over recommended limits, can leave
residual. Any residue usually goes away by itself within 24/48 hours, otherwise, being soluble in water,
it is enough to use a wet cloth for cleaning. If you desire to obtain an average of 1 meter visibility after 60 seconds from
shooting, as specified by the standard EN 50131-8:2019, used as reference by all manufacturers of fog generators, the
number of shooting seconds it is to be reduced in half.
RECOMMENDED SHOOTING TIME ACCORDING TO THE VOLUME SPACE TO PROTECT (m
3
)
Fogging systems Density
®
Basic is able to produce fog based on second by second setting.
The maximum quantity of 1,5 ml/s allows to fill an area of around 135 cubic meters.
There might be cases in which, due to specific characteristic of the location, nozzle type, levels of temperature
and air pressure, degree of the fog density and light in the target area, the shooting time can be increased or
decreased.
For example, above 3 mt of height the shooting time must be integrated and above 5 mt, every additional meter
should be considered as double.
HxLxP-------- Height x Width x Depth of the area to protect
D------------- Density of the produced fog
V------------- Temperature and air pressure
R------------- Acceptable residue in case of saturation of V parameter
I-------------- Intensity of the surface light
(HxLxP) x D x V x R x I
The following tables indicate the suggested fog emission in relation to the number of seconds of shooting set in
average condition of temperature, air pressure and humidity.
To correctly dimension the units it is needed to verify that the saturation of the area occurs in faster time than
the one supposed for the theft.
On the Density
®
Basic mainboard are present two serial ports connectors (J11 and J6) that are reserved for
connection to expansion modules and communication devices specially designed by the manufacturer.
To allow advanced diagnostics, it is possible to connect a personal computer with Microsoft Windows or Linux
operating system using a microUSB cable to the J1 port. Using a generic terminal emulator it will be possible to
display the operating parameters of the device on the screen. The same port can be used for any firmware updates
of the device. We recommend that you refer to your product distributor for more information about advanced
diagnostic.
