6-1. Names of the parts
6-1. Names of the parts
The names of the main unit parts are as follows:
Plate
Overall
Bottom
surface
Right
side
[Power] indicator
[Vehicle] indicator
Strap hole
[PC communication] indicator
Rubber cap
[SD memory card access] indicator
(only the model with
an SD memory card slot)
Connector jack (diagnosis connector on the vehicle side)
Rubber cap
USB connector
SD memory card slot*
(only the model with an SD memory card slot)
*Rubber caps are provided for "SD memory card slot".
The model without an SD memory card slot
is covered with a side panel.
