8-2. After diagnosis
Exit the diagnostic software.
Turn the vehicle starter switch (ignition switch) OFF.
Ensure that the connector lock is released.
Connector lock
(lock released)
[CAUTION]
If the main unit is disconnected from the diagnosis connector on the vehicle side while the
connector lock is locked, it may damage the diagnosis connector on the vehicle side and/or
the main unit connector.
T03030J
1
3
2
8-2. After diagnosis
8. Use cases
