8-1. Before starting diagnosis
Ensure that the connector lock is released.
Reference:
Page 19 Connecting to the vehicle
(Chapter 7 Connection)
Connector lock
(lock released)
Connect the main unit to the diagnosis connector on the
vehicle side.
Reference:
Page 19 Connecting to the vehicle
(Chapter 7 Connection)
Connected to vehicle side
diagnosis connector.
T03030J
T03031J
1
2
[CAUTION]
If the main unit is connected to the diagnosis connector on the vehicle side when the
connector lock is locked, it may damage the diagnosis connector on the vehicle side.
8-1. Before starting diagnosis
