PROTECTION AGAINST MOISTURE DAMAGE
It is important to take proper precautions during
installation to ensure that moisture will not come in
contact with the electrical connections or components
of the system. The integrity of the system regarding
moisture protection must be maintained for proper
operation and is the responsibility of the installer.
NOTE
NEMA 4 / IP66 / IP67 rating requires the use of IP
washers / IP glands (M25) .
If conduit is used, we recommend installing drains,
according to local codes, at water collection points
to automatically drain accumulated moisture. It is also
recommended to install at least one breather, according
to local codes, at upper locations to provide ventilation
and allow water vapor to escape.
Conduit raceways should be inclined so that water will
flow to low points for drainage and will not collect inside
enclosures or on conduit seals. If this is not possible, install
conduit drains above the seals to prevent the collection
of water or install a drain loop below the detector with a
conduit drain at the lowest point of the loop.
Conduit seals are not required for compliance with
explosion-proof installation requirements, but are highly
recommended to prevent water ingress in outdoor
applications. Units with M25 thread must use an IP66
washer to prevent water ingress.
NOTE
For optimum performance and maximum service
life, care should be taken to protect the Model HD
from corrosive contaminants in the atmosphere.
Setting
° F (° C)
Tolerance
° F (° C)
Spacings feet (meters)
RTI
1
Color Coding
2
UL ULc FM
140 (60) +7/-8 (±4) 50 (15) 50 (15) 25 (8) Fast Black
160 (71) +7/-8 (±4) 25 (8) 25 (8) 25 (8) Fast Black
190 (88) +7/-8 (±4) 50 (15) 50 (15) 25 (8) Fast White
210 (99) +7/-8 (±4) 25 (8) 50 (15) 30 (9) V- Fast White
225 (107) +7/-8 (±4) 25 (8) 50 (15) 30 (9) V- Fast White
275 (135) ±10 (±6) 25 (8) 50 (15) 30 (9) V- Fast Blue
325 (163) ±10 (±6) 50 (15) 50 (15) 30 (9) V- Fast Red
360 (182) ±10 (±6) 25 (8) 50 (15) 30 (9) V- Fast Red
450 (232) ±15 (±8) 25 (8) 50 (15) 30 (9) V- Fast Green
500 (260) ±15 (±8) 50 (15) 50 (15) 30 (9) V- Fast Orange
600 (316) ±20 (±11) N/A 50 (15) 30 (9) V- Fast Orange
725 (385) ±20 (±11) N/A 50 (15) 30 (9) V- Fast Orange
Table 1—Temperature Specications and Maximum Detector Spacing Values
1 Response Time Index - Measurement of the Heat Detector’s sensitivity and speed of response. For more information, refer to standards
FM 3210 and EN 54-5.
2 Color of the printing on the detector.
