13.1
BASIC SETUP SUBMENU
The tag number identifies a specific device. Changing units affects the engineering units
that are displayed. Re-ranging changes the analog output scaling.
1 Tag
Press to access the Tag number menu. Enter the device tag number as desired.
2 PV Unit
Press to access PV Unit submenu. Select %LEL for standard combustible applications.
– % LEL
– ppm
– Vol %
3 Range Values
Press to access Range Values submenu.
1 URV 20-100% LEL (upper range value).
2 LRV 0% LEL (lower range value).
3 USL 100% LEL (upper sensor limit).
4 LSL 0% LEL (lower sensor limit).
4 Device Information
Press to access device information submenu:
1 Tag xxxx
2 Date 6/30/2000
3 Descriptor (text associated with the field device that can be used by the operator in any way).
4 Message (text associated with the field device that can be used by the operator in any way).
5 Model: Eclipse
6 Write protect xx. This indicates whether variables can be written to the device, or whether commands
that cause actions to be performed in the device can or cannot occur.
7 Revision #’s. See Revision #’s submenu below.
8 Final asmbly num
9 Dev id xxxx (a number is used to identify a unique field device).
Revision # submenu
offers selection options for:
1 Universal rev
2 Fld dev rev
3 Software rev xx
5 Gas
Type of gas being detected.
1 Tag
2 PV Unit xxxxx
3 Range Values
4 Device Information
5 Gas xxxxxx
To Next Page
