DETAILED SETUP MENU
1 Sensor Information
This menu provides detailed information on the internal detector operations. Submenu
options include:
1 PV USL xxxx. The upper sensor limit value defines the maximum usable
value for the upper range of the sensor.
2 Active xxxx (output value of the active sensor).
3 Reference xxxx (output value of the reference sensor).
4 Ratio xxxx (the ratio of the active sensor over the reference sensor).
5 Absorption xxxx % (the gas absorption expressed in percent).
6 Span Factor xxxx (the number used in calibrating this specific device).
 7SnsrtempxxdegC (thetemperatureofthesensorthatismaking
the process measurement).
8 Vol % @ 100%LEL (the % volume of gas equal to 100% LEL).
9 Coefficient A
Coefficient B
Coefficient C
Coefficient D
Coefficient E
2 Gas Type
Select the gas to be detected here. Submenu options include:
– Spcl
Spcl Gas Coef A
Spcl Gas Coef B
Spcl Gas Coef C
Spcl Gas Coef D
Spcl Gas Coef E
Spcl Gas Vol %
– Methane
– Ethane
– Propane
– Ethylene
– Propylene
– Butane
– Spare 6
– Spare 7
– Spare 8
1 Sensor Information
2 Gas Type xxxxx
3 Output Condition
4 Device Information
5 Write Protect
