G-6 95-8526
13.1
Fault Status Word
These bits are used to signal the active faults of the device.
Control Words
Setting values in this area of memory initiates action in the device. For example, it may start a calibration sequence.
The device automatically clears command word bits after the function is performed.
Name Bit
Calibration Fault 0
Dirty Optics 1
Open Lamp 2
Cal Active at start 3
EE Error 1 4
EE Error 2 5
Ref ADC Saturated 6
Active ADC Saturated 7
Bad 24 volts 8
Bad 12 volts 9
Bad 5 volts 10
Zero Drift 11
Flash CRC Error 12
Ram Error 13
Eclipse Control Words
Description Address Value
Command Word 1 40301 See below
Command Word 2 (Reserved) 40302
Reserved 40303
to
40306
