Command Word 1
Event Logs
Fault and calibration logs are held in this area of memory.
Description Bit
Start Calibration 0
Abort Calibration 1
Warm up Mode 2
Low Alarm Active 3
High Alarm Active 4
Output Current Fixed 5
Modbus Write Protect 6
Calibration Input Active 7
Magnetic Switch Active 8
Hart Initiated Self Test 9
Reserved 10
Response Test Active 11
Manual Self Test Active 12
End Response Test 13
Reserved 14
Start Manual Self Test 15
Eclipse Event Logs
Description Address Value Notes
Event Hour 40401 Unsigned Long LSW 1 of 10 logs
40402 Unsigned Long MSW
Event ID 1 40403 See Codes
Event Hour 40428 Unsigned Long LSW Last of 10
40429 Unsigned Long MSW
Event ID 10 40430 See Codes
Event Hour 40431 Unsigned Long LSW 1 of 10 logs
40432 Unsigned Long MSW
Calibration Event ID 1 40433 See Codes
Event Hour 40458 Unsigned Long LSW Last of 10
40459 Unsigned Long MSW
Calibration Event ID 10 40460 See Codes
