Det-Tronics PIRECL - Eagle Quantum Premier (EQP) Compatibility (Continued); EQP Configuration and Operation; EQP Onboard HART Port Usage; EQP Multi-Colored LED Operation

H-2 95-8526
13.1
CONFIGURATION AND OPERATION
Configuration of the EQP Eclipse is accomplished using Det-Tronics Safety System Software (S3) that is running on the
EQP Operator Interface Station (OIS).
ONBOARD HART PORT
The on-board HART port is functional on the EQP Eclipse, however, it should not be used for device configuration
purposes. All EQP device configuration should be performed using the S3 program.
MULTI-COLORED LED
Operation of the status indicating LED is identical to all other PIRECL versions.
REMOTE CALIBRATION OPTION
Operation of the remote calibration option is identical to all other PIRECL versions.
ANALOG OUTPUT
A 4-20 mA analog current output is not available with EQP PIRECL.
RS-485 COMMUNICATION
RS-485 communication is not available with EQP PIRECL.
CALIBRATION ROUTINE
The calibration procedure for the EQP PIRECL (normal and zero calibration) is identical to all other PIRECL versions.
NOTE
For complete information regarding installation, conguration or operation of the Eagle Quantum Premier system,
refer to form 95-8533 (Eagle Quantum Premier hardware manual) or form 95-8560 (Safety System Software
manual).
ECLIPSE OPERATION WITH EAGLE QUANTUM PREMIER
Table H-2—Typical Update Rate for PIRECL in an EQP System
Field Device Transmit time to Controller (sec)
PIRECL
Gas Alarms
Gas Level
Immediate
1
Device Fault 1
