4.1 95-862016
MAIN MENU
PROCESS VARS  DISPLAY STATUS  DEVICE STATUS  DISPLAY SETUP  DEVICE SETUP  DEVICE CAL  DEVICE TEST 
PROCESS VARS
GAS NAME XXXX GAS VALUE X.XX ANALOG INPUT XX.XX MA URV X.XX LRV X.XX FAULT Y/N
DEVICE STATUS
GENERAL INFO  FAULT/STATUS  TX INFO  SENSOR INFO  HISTORY  DEBUG MENU 
March 1, 2013
UD20
GT3000
Detector Electronics
1.26
FAULT/STATUS
OP MODE XXXXX CAL STATE XXXXX TX STATUS Y/N TX FAULT Y/N SENSOR STATUS Y/N SENSOR FAULT Y/N
RTC
SECONDS XX MINUTES XX HOURS XX DAY XX MONTH XX YEAR XX
GENERAL INFO
MANUFACTURER  MODEL FGP_TX TAG XXXXX DESCRIPTOR XXXXX DATE DD/MMM/YYYY MESSAGE XXXXX FINAL ASSY NUM XXXXX
DEVICE ID XXXXX
HISTORY
TX HISTORY  SENSOR HISTORY  CALIBRATION LOG  EVENT LOG 
CALIBRATION LOG
CAL ID XXX DATE DD/MMM/YYYY TIME HH:MM:SS
ZERO XX.XX
SPAN XX.XX
EVENT LOG
EVENT XXXXX DATE DD/MMM/YYYY
TIME HH:MM:SS
DEVICE SETUP
HART OPTION  RTC  WRITE PROTECT 
HART OPTION
TAG XXXXX DESCRIPTOR XXXXX DATE DD/MMM/YYYY MESSAGE XXXXX FINAL ASSY NUM XXXX
D/A TRIM
ZERO TRIM GAIN TRIM
RTC
SECONDS XX MINUTES XX HOURS XX DAY XX MONTH XX YEAR XX
DEVICE CAL
CAL GAS CONC XX.XX CALIBRATION  CHANGE SNSR TYPE
DEVICE TEST
SELF TEST RESPONSE TEST LOOP TEST  D/A TRIM 
LOOP TEST
SET 4-20 MA 
SET 4-20 MA
3.5 MA 4 MA 6 MA 8 MA 10 MA 12 MA 14 MA 16 MA 18 MA 20 MA
CALIBRATION
EXECUTE ABORT
TX STATUS
TX FAULT ON/OFF WARM UP ON/OFF CHANGE CONFIG ON/OFF MULTI DROP ON/OFF WRITE PROTECT ON/OFF
SELF TEST ON/OFF RESPONSE TEST ON/OFF CURRENT FIXED ON/OFF LOOP TEST ON/OFF FACTORY MODE ON/OFF SNSR ASSY REMOVE ON/OFF
DEBUG MENU
MODBUS ERRORSXXXX
6901 West 110
th
Street
Minneapolis, MN 55438 USA
DISPLAY STATUS
DISPLAY INFO  FAULT/STATUS  DEBUG MENU 
DEBUG MENU
HART ERRORS XXXXX LCD TEST ANALOG INPUT XX.XX MA
FAULT/STATUS
OP MODE XXXXX FAULT Y/N STATUS Y/N
DISPLAY INFO
F/W REV XX.XX
SERIAL NUMBER XXXX TEMPERATURE XX.XX C FACTORY CONFIG
FAULT
ADC FAULT ON/OFF ANALOG CODE FLT ON/OFF FLASH FAULT ON/OFF RAM FAULT ON/OFF WDT FAULT ON/OFF 3V FAULT ON/OFF INPUT LOOP FAULT ON/OFF
STATUS
ANY FAULT ON/OFF CAL ACTIVE ON/OFF WARM UP ON/OFF INPUT HART ON/OFF
TX FAULT
EE FAULT ON/OFF
ADC FAULT ON/OFF
DAC FAULT ON/OFF
LOW VOLTAGE ON/OFF
FLASH CRC FAULT ON/OFF RAM FAULT ON/OFF TEMP FAULT ON/OFF
SOFTWARE FAULT ON/OFF
EE SAFETY FAULT ON/OFF ZERO DRIFT FAULT ON/OFF
SENSOR MISMATCH ON/OFF SENSOR FAULT ON/OFF
SENSOR STATUS
SENSOR FAULT ON/OFF WARM UP ON/OFF CAL ACTIVE ON/OFF CAL SWITCH ON/OFF WRITE PROTECT ON/OFF
EOL SENSOR ON/OFF CHANGE CONFIG ON/OFF
SENSOR FAULT
CAL FAULT ON/OFF EE FAULT ON/OFF
ADC FAULT ON/OFF ADC CNTR FAULT ON/OFF 3V FAULT ON/OFF ZERO DRIFT FAULT ON/OFF
FLASH CRC FAULT ON/OFF
RAM FAULT ON/OFF TEMP FAULT ON/OFF
COMM FAULT ON/OFF
TX HISTORY
RUNNING HOURS XXXXX MAX TEMP XX.XX C
MAX TEMP TIME XXXXX MIN TEMP XX.XX C
MIN TEMP TIME XXXXX
SENSOR HISTORY
RUNNING HOURS XXXX MAX TEMP XX.XX C MAX TEMP TIME XXXXX
MIN TEMP XX.XX C MIN TEMP TIME XXXXX
TX INFO
RTC  H/W REV XX.XX F/W REV XX.XX
SERIAL NUMBER XXXXX UNIVERSAL REV XXXXX FLD DEV REV XXXXX RUNNING HOURS XXXXX TEMPERATURE XX.XX C
SENSOR INFO
SENSITIVITY XXX.XX
GAS TYPE XXXXX H/W REV XX.XX F/W REV XX.XX
SERIAL NUMBER XXXXX REV XXXXX USL XX.XX LSL XX.XX RUNNING HOURS XXXXX CAL POINT ZERO XX.XX CAL POINT SPAN XX.XX PPM HOURS XXXXX TEMPERATURE XX.XX C
WRITE PROTECT
CHANGE STATE CHANGE PASSWORD WRITE PROTECT XXXXX
DISPLAY SETUP
CONTRAST CONTROL INPUT LOOP CAL
