8525-0374-0M Rev A y Physician’s Scale Owner’s Manual
2
UNPACKING
Remove the scale base with platform cover, column with weigh beam headpiece, height
measuring rod, wheel assembly, and hardware kit from the shipping carton. After removing
from the carton, check for any damage that may have occurred during shipment. Note that
the purchaser is responsible for filing all claims for any damages or loss incurred during
transit. Keep and use the original carton and packing material for return shipment if it should
become necessary.
SPECIFICATIONS
Models: 337, 338, 339, 349 437, 438, 439, 448, 449 2371, 2381, 2391, 2491
Capacity:
440 lb x 4 oz or
200 kg x 100 g
450 lb x 4 oz 200 kg x 100 g
Height Measurement Range: 24-84” (60-212 cm)
Height Graduation: 0.125” (0.1 cm)
Platform Size: 14.75” x 10.75” (37.5 x 27.3 cm)
Column
Weigh Beam
Height Rod
Rear Wheels
Scale Base
Platform Cover
Large Poise
Small Poise
