3.3 Setting the machine shutdown parameter
Setting the ″machine shutdown″ parameter is very useful if you don’t want to
penalize productivity by shutting down the machine even though the measured
bad parts are isolated from production by a recovery system controlled by the MIN
and MAX contacts.
The parameter to be adjusted is the number of consecutive measurements
outside tolerances after which the machine will be shutdown. This parameter is
adjusted by default to the minimum, that is, after 1 measurement outside
tolerance. The maximum is 25 measurements.+
CHAN 1 : +0.000mm
CHAN 2 : +0.000mm
V
V
MEASURE
-> OPTIONS
PARAMETERS
DISPLAYS
V
V
MEASURE MASKING
ACTION DELAY
-> MULTI-PART ACTION
V
CHAN 1 TRIGGER RELAY
FOR 3 MEASUREMENTS
NOT WITHIN TOLERANCE
VALIDATE BY OK
CHAN 2
appears only if
you have a PC2003B
(dual channel) device.
V
V
MULTI-PART ACTION :
-> CHANNEL 1
CHANNEL 2
V
V
Define the number of
consecutive measurements
outside tolerance after which
you want to shutdown the
machine
V
V
MEASURE MASKING
ACTION DELAY
-> MULTI-PART ACTION
V
X2
V
V
MULTI-PART ACTION :
-> CHANNEL 1
CHANNEL 2
V
X3
This page appears only if
you have a PC2003B
(dual channel) device.
