Detector PC2003 - PC2003 Programming Modes Summary

Programming Manual
PC 2003 Amplifier English
Page 12/14
PROPC2003EN – Index A
3.4 Table of the programming modes
This table is a summary of all the menus and the adjustments present in the
amplifier.
>TOLERANCES
REFERENCE
STATISTICS
TOLERANCES :
> CHANNEL 1
> CHANNEL 2
Adjusting the tolerance in a range of ± 2mm
REFERENCE
ADJUST:
CHANNEL 1 OR 2
> MANUAL
AUTOMATIC
Calibrating the reference
value on a part between
0.300 and 0.400mm
TOLERANCES
>REFERENCE
STATISTICS
REFERENCE :
> CHANNEL 1
> CHANNEL 2
REFERENCE
ADJUST :
CHANNEL 1 OR 2
MANUAL
> AUTOMATIC
-Calibrating the reference
value from 0.300 to 0.4000
mm in manual.
- Choice of number of
samples (1 to 25).
- Measurement in automatic
- Calculation of the mean
STATISTICS CHOICE
> STANDARD
SAMPLING
STANDARD :
Display of the measurement statistics: number of
measurement, number of measurement undersized,
number of measurement oversized. Reset to zero
with OK.
>MEASURE
OPTIONS
PARAMETERS
DISPLAYS
TOLERANCES
REFERENCE
>STATISTICS
STATISTICS CHOICE
STANDARD
>SAMPLING
SAMPLING :
- Choice of the number parts samples (1 to 200)
- Measurement in automatic
- Calculation of the mean + min. value and max.
value maxi.
>MEASURE MASKING
ACTION DELAY
MULTI-PART ACTION
MEASURE MASKING :
> CHANNEL 1
> CHANNEL 2
INACTIVE disables the function.
MEASUREMENT MASKING after 1 to 25
measurements.
Description of the function in subsection 3.1,
pages 8
MEASURE MASKING
>ACTION DELAY
MULTI-PART ACTION
ACTION DELAY:
> CHANNEL 1
> CHANNEL 2
INACTIVE disables the function.
Measurement Transfer after 1 to 25
measurements.
Description of the function in subsection 3.2,
page 9
MEASURE
>OPTIONS
PARAMETERS
DISPLAYS
MEASURE MASKING
ACTION DELAY
>MULTI-PART ACTION
MULTI-PART ACTION :
> CHANNEL 1
> CHANNEL 2
INACTIVE disables the function.
Machine Shutdown after 1 to 25 measurements.
Description of the function in subsection 3.3,
page 11
