Programming Manual
PC 2003 Amplifier
English
Page 13/14
PROPC2003EN – Index A
>TARE
MEAS. ARM CORRECT.
TOLERANCES MODE
MEASUREMENT MODE
TARE :
> CHANNEL 1
> CHANNEL 2
Adjustment of the tare of
the sensor in the probe.
(See Integration an
mechanical adjustment
for gauge)
TARE
>MEAS.ARM CORRECT.
TOLERANCES MODE
MEASUREMENT MODE
This parameter is used only for the length gauges
L00A and L00B.
It allows to correct the ratio of the measuring arm.
TARE
MEAS.ARM CORRECT.
>TOLERANCES MODE
MEASUREMENT MODE
TOLERANCES MODE :
INTERVALS
VALIDATE BY OK
Allows to choose the
display mode of
tolerances :
INTERVALS :
Ex : +0.05 / -0.05
LIMITS : 5.95/6.05
>SENSOR PARAMETERS
ADDITIONNAL DATA
PROGRAM SETTINGS
ADMIN
TARE
MEAS.ARM CORRECT.
TOLERANCES MODE
>MEASUREMENT MODE
NUMBER OF SENSORS
ONE
VALIDATE BY OK
Allow to select the number
of sensor: ONE, TWO
INDEPENDENT, TWO
COUPLED and HIRTH.
Then select the
measurement mode:
PEAK, PEAK
CONTROLLED or
STABILIZED.
SENSOR PARAMETERS
>ADDITIONNAL DATA
PROGRAM SETTINGS
ADMIN
Extended data are released via 4 digits (release code), allowing additional
data to be obtained at the output of the RS232 link exploited and analyzed
by a specific software.
speed of the serial link : 9.6 Kbauds
parity of the serial link : NONE
MEASURE
OPTIONS
>PARAMETERS
DISPLAYS
SENSOR PARAMETERS
ADDITONNAL DATA
>PROGRAM SETTINGS
ADMIN
>CONFIGURATION
GOOD MEASUREMENT
MI/MA MEASUREMENT
Configuration of the logical outputs :
INACTIVE 60S: As soon as you enter the
programming mode, measurements are no longer
taken. After 60 seconds without any manipulation
of the keypad, the measurement mode is returned
to and therefore measurements are again taken.
INACTIVE INF: the same as for adjustment
INACTIVE 60S; but without automatically return to
measure mode.
ACTIVE 60S: Your entry in the programming
mode doesn’t stop measurements as in adjustment
INACTIVE. After 60 seconds without any
manipulation on the keypad, there is an automatic
exit from the programming mode
ACTIVE INF: the same as for adjustment ACTIVE
60S; but without automatically return to measure
mode.
MEASURE
OPTIONS
>PARAMETERS
DISPLAYS
SENSOR PARAMETERS
ADDITIONNAL DATA
>PROGRAM SETTINGS
ADMIN
CONFIGURATION
>GOOD MEASUREMENT
MI/MA MEASUREMENT
Memorization of the output good measurement:
STORED: When a part is good, the output relay
“good” closes and stays closed until the next valid
signal. The state of the output is stored.
NOT STORED: When a part is good, the output
relay “good” closes for 50ms minimum and then
reopens. The state of the output is not stored.
(adjustment by default)
