Programming Manual
PC 2003 Amplifier
English
Page 3/14
PROPC2003EN – Index A
The Realtime mode can be described as follows:
1- The sensor, mounted at a station (like a drill tool), comes in contact with the
part (during the work) until it is at the machining end stop.
2- Then the valid pulse is sent by the machine; the instantaneous (current
position of sensor) value is directly compared to the reference and the
tolerances.
3- The amplifier triggers the relays based on the result of its comparison (good
part, min. part, max. part or machine shutdown).
4- If the measured part is not within tolerance, the machine can be shutdown
using these relays. On the contrary, if the measured part is within tolerance,
the measurement is reset and awaits the next valid signal.
Other functions are present in this amplifier, such as the masking of a
measurement during a material feed operation, the transfer of a measurement, or
the machine shutdown function.
The PC2003 is suitable for most multi-spindle/single spindle machine tools which
are cam driven or numerically controlled. Thanks to the user friendliness of the
menus, any user can rapidly plug in and use the amplifier and easily navigate
within it. In addition, once adjusted, the amplifier can be locked to prevent any
handling errors.
All the menus and functions are detailed in the rest of this guide.
