P.9
F1
8A-T
F2
250mA-F
3 - ELECTRONIC CONTROL UNIT CONNECTIONS
The installer must connect the 230 Vac 50 Hz power supply and the various devices provided
for automa!on.
The connec!ons between the control unit, motor, encoder and transformer are already made
by the manufacturer and must not be modified in any way
ATTENTION:
To facilitate connec!on to the control unit, remove the connector with the help of a
screwdriver. Once the wiring is complete, insert it in the correct posi!on.
With clamps, block the wires in the slots adjacent to the connector. Use cables of suitable
sec!on and type.
