ElectroVap RTH-V2
20
Pictures and values are not contractual - The devices may be subject to changes without notice
3.4 STEAM OUTLET
1. 


2. 
3. 
• 
• 
4. 

• 
•    


Make sure that the steam hose is not leaky / or does not form a water pocket. 

Example b
* Optional stainless steel reducer Ø60/Ø40 mm (See page 14)
RTH  
Number of steam outlets
1 1
Diamètre tuyau sortie vapeur
 
Example a
Keep the hose tight before
joining it to the sleeve(s).
Ring bearing clamp
supplied with optional
stainless steel union
Ø60 mm stainless steel union
(option)
70-90 ring clamp supplied
with the humidier
Radius of bend for steam hose :
• Ø 40 mm steam hose = 400 mm minimal
radius
• Ø 60 mm steam hose = 750 mm minimal
radius
