Devatec ElectroVap - Settings Adjustment: System Parameters

ElectroVap RTH-V2
42
Pictures and values are not contractual - The devices may be subject to changes without notice
CTRL SIGNAL TYPE
XXXX XXX
HUMIDIFIER
SETUP
PROD. LIMITATION
XXX %
END OF SEASON DRAIN?
XXX
SET POINT
XX % RH
PID SETTINGS
P: XX I: XX D: XX
EOS TIMER
SETTING: XX Hrs
CONTROL
SYSTEM
Adjusting of Steam Production
1 STEP - On / O󰀨: 20 % > Limit > 100 %
Other control: 50 % > Limit > 100 %
Adjusting of control signal:
. 1 STEP ON /OFF,
. 4 - 20mA CONTROL, 0 - 5V CONTROL, 0 - 10V
CONTROL, 2 - 10V CONTROL .
. DEVATEC SENSOR, 0 - 5V SENSOR, 0 - 10V
SENSOR.
. DIGITAL SENSOR, DIGITAL CTRL.
5.2 SETUP MENU
Display when a RH sensor is used
Setting the set point ( 1 to 99 % Rh)
Setting of PID. ( 0 to 50 : P - I – D)
Setting : End Of Season (EOS)
Enable or disable of drain system (OFF or ON)
Timeout EOS (1 to72 hrs)
ou
IF
ou
IF
