ElectroVap RTH-V2
26
Pictures and values are not contractual - The devices may be subject to changes without notice
L2
L1
N
L3
L
PE
T
L2
L1
N
L3
L
PE
E) U=3x208-220-230V
F) U=3x440-460-480-575-600V
RTH 8 - 36
Q2 : 3 poles
Q1 : 2 poles 2A
Power in
3x
208-230V
50-60Hz
GROUND
RTH 7 - 50
GROUND
Q2 : 3 poles
Q1 : 2 poles
Power in
3x
xxx VAC
50-60Hz
T : Transformer
prim: 460V / sec:230V
S= 100 VA
(see page 27)
