LT-2023
35
Figure 15A - GSE Compressor With Head Removed
Sleeve
Valve Plate
Rod Screw
Rod (beneath
cup retainer)
Cup Seal
Cup
Retainer
Reed Valve
or Flapper
Retainer
Intake
Fitting
PR Valve
Compressor
Head
Head Gasket
Screw
Connecting
Tubes
O-Ring
Spacer
Sleeve
Exhaust
Fitting
FIGURES, DIAGRAMS, AND VIEWS
