DeVilbiss PRI Pro Lite - Page 11

EN
1
2
Remove the fluid adjusting knob to relieve spring pressure against needle collar.
CAUTION
NOTE
Pull the trigger and hold while tightening or loosening the fluid tip, or,
When replacing the fluid tip or fluid needle, replace tip, needle and fluid packing at the same time.
Using worn parts can cause fluid leakage. Do not overtighten.
DISASSEMBLY TIP & NEEDLE
To prevent damage to fluid tip or fluid needle, be sure to either:
SB-E-2-859 R1.1
11/24
