Always turn off air supply and relieve pressure when gun is not in use.
Spray edges first. Overlap each stroke a minimum of 75%. Move gun at a constant speed.
Adjust inlet air pressure if required.
Turn fluid adjusting knob counter clockwise until first thread shows.
The gun is not designed for use with highly corrosive and/or abrasive materials.
To avoid premature degradation of parts, DeVilbiss recommends the gun is washed in neutral
cleaning solution (pH 6 to 8).
The gun is not designed to be cleaned within an ultrasonic bath.
Turn spreader valve adjusting knob (45) counter clockwise to fully open.
Connect the gun to a clean, moisture and oil free air supply using a conductive hose of at least
8mm I.D.
Hold gun perpendicular to surface being sprayed. Arcing or tilting may result in uneven coating.
The pattern size can be reduced by turning spreader valve knob (45) clockwise.
If finish is too wet, reduce fluid flow by turning fluid adjusting knob (28) clockwise. If
atomisation is too coarse, increase air inlet pressure. If too fine, reduce inlet pressure.
The recommended spray distance is 150-200mm.
Turn fluid adjusting knob (28) clockwise to prevent fluid needle movement.
Test spray. If the finish is too dry, reduce airflow by reducing air inlet pressure.
Mix coating material to Manufacturer's instructions and strain material.
IMPORTANT: This spraygun is suitable for use with both waterbased and solvent based coating
materials.
If there is any doubt regarding the suitability of a specific material, contact your DeVilbiss Distributor
or DeVilbiss direct.
