dLAN network 21
devolo dLAN 200 AV USB extender
Expanding an existing dLAN 200 AV network by
adding a new dLAN 200 AV USB extender (Fig. 2)
If you have already secured your existing dLAN 200 AV
network using the encryption button, use the same
method to integrate further adapters. Once you have
successfully connected the new
dLAN 200 AV USB extender, first press the encryption
button (approx. one second) of one of your network’s
existing adapters, then press the encryption button
(approx. one second) of your new
dLAN200AVUSBextender within two minutes.
That's it! The new dLAN 200 AV USB extender is now
integrated in your network. To integrate additional
adapters in your network, repeat the above steps.
fig. 2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Devolo dLAN 200 and is the answer not in the manual?

Devolo dLAN 200 Specifications

General IconGeneral
InterfaceEthernet / WLAN
Connectivity technologyWired & Wireless
Ethernet LAN (RJ-45) ports3
Chipset-
InternalNo
Product colorWhite
LED indicatorsYes
Modulation1024-QAM, 256-QAM, 64-QAM, BPSK, OFDM, QPSK
Wi-Fi bandSingle-band (2.4 GHz)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100BaseT(X)
Top Wi-Fi standardWi-Fi 4 (802.11n)
Security algorithmsWEP, WPA, WPA2
Networking standardsIEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u, IEEE 802.3x
Spread spectrum methodDSSS
Ethernet LAN data rates10, 100 Mbit/s
Maximum data transfer rate200 Mbit/s
Maximum operating distance300 m
WLAN data transfer rates supported300 Mbit/s
AC input voltage230 V
AC input frequency50 Hz
Dimensions (WxDxH)110 x 68 x 49 mm
Non-operating relative humidity (non-condensing)10 - 90 %
Input current0.13 A
Power consumption (typical)5.6 W
Storage temperature (T-T)-25 - 70 °C
Operating temperature (T-T)0 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth68 mm
Width110 mm
Height49 mm
Weight200 g
