Residual Risks
• The following risks are inherent to the use of
these machines:
– injuries caused by touching the rotating parts.
– injuries caused by disruption of the cutting
disc.
• These risks are most evident:
– within the range of operation
– within the range of the rotating machine parts
• In spite of the application of the relevant
safety regulations and the implementation of
safety devices, certain residual risks cannot be
avoided.
These are:
– Impairment of hearing.
– Risk of accidents caused by the uncovered
parts of the rotating cutting disc.
– Risk of injury when changing the disc.
– Risk of squeezing fingers when opening the
guards.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual before use.
Wear ear protection.
Wear eye protection.
Bore Diameter
DATE CODE POSITION (FIG. 1)
The Date Code (bb), which also includes the year of
manufacture, is printed into the housing.
Example:
2013 XX XX
Year of Manufacture
Package Contents
The package contains:
1 Chopsaw
1 Cutting disc
1 Hex key
1 Instruction manual
1 Exploded drawing
• Check for damage to the tool, parts or
accessories which may have occurred during
transport.
• Take the time to thoroughly read and
understand this manual prior to operation.
Description (fi g. 1, 7)
WARNING: Never modify the power
tool or any part of it. Damage or
personal injury could result.
a. Lock pin
b. Spark deflector screw
c. Spark deflector
d. Base
e. Fence
f. Vise
g. 8mm hex wrench
h. Crank
i Vise lever
j. Wheel
k. Spark guard
l. Wheel lock lever
m. Trigger switch
n Padlock hole
o. Extra blade bolt
p. Extra blade bolt washer
q. Quick-change blade clamp (fig. 7)
INTENDED USE
Your D28715 chop saw has been designed for the
cutting of variously shaped steel materials.
DO NOT use under wet conditions or in presence of
flammable liquids or gases.
The D28715 chop saw is a professional power tool.
DO NOT let children come into contact with the
tool. Supervision is required when inexperienced
operators use this tool.
• This product is not intended for use by persons
(including children) suffering from diminished
physical, sensory or mental abilities; lack of
experience, knowledge or skills unless they are
supervised by a person responsible for their
safety. Children should never be left alone with
this product.

DeWalt D28715 Specifications

General

Product type	Standard miter saw
Cutting capacity 0°	130 mm
Power consumption (typical)	1350 W
Bevel type	Single bevel
Table saw mode	-
Idle speed (max)	4000 RPM
Sound pressure level	112 dB
Sound level uncertainty	3, 100 dB
Cross cut capacity (0° x 0°)	140 x 140 mm
Compound cut capacity (45° x 45°)	120 x 120 mm
Input power	2200 W
Power source	AC
Blade diameter	355 mm
Blade thickness	2.5 mm

Weight and Dimensions

Width	520 mm
Height	435 mm
Weight	18000 g
