DeWalt DCS778 - Prior to Operation; Instructions for Use

12
ENGLISH

WARNING: Always check that the blade does not touch the table at
the rear of the slot or at the front of the rotating arm at 90° vertical
and 45° bevel positions. Do not switch on before having checkedthis!
Adjusting the Fence (Fig.I)
Turn the sliding fence lock knob
9
anti-clockwise to loosen. Move the
sliding fence
16
to a position that avoids the blade cuts it,then tighten the
fence lock knob by turningclockwise.
Checking and Adjusting the Blade to the Fence
(Fig.B, J, K)
1. Slacken the mitre latch
13
.
2. Place your thumb on the mitre arm
12
and squeeze the mitre latch
13
to release the rotating table/mitre arm
14
.
3. Swing the mitre arm until the latch locates it at the 0° mitreposition.
4. Pull down the head and lock it in this position using the lock down
button
22
.
5. Check that the two 0° markings
40
on the mitre scale
15
are
justvisible.
6. Place a square
41
against the left side of the fence
16
and blade
8
.

WARNING: Do not touch the tips of the blade teeth with thesquare.
7. If adjustment is required, proceed asfollows:
a. Loosen the screws
42
and move the scale/mitre arm assembly left
or right until the blade is at 90° to the fence as measured with the
square (Fig.J).
b. Retighten the screws
42
.
Checking and Adjusting the Blade to the Table
(Fig.L–N)
1. Loosen the bevel clamp handle
19
(Fig.L).
2. Press the saw head to the right to ensure it is fully vertical and tighten
the bevel clamphandle.
3. Place a set square
41
on the table and up against the blade
8
(Fig.M).

WARNING: Do not touch the tips of the blade teeth with thesquare.
4. If adjustment is required, proceed asfollows:
a. Loosen the bevel clamp handle
19
and turn the vertical position
adjustment stop screw
43
in or out until the blade is at 90° to the
table as measured with thesquare.
b. If the bevel pointer
44
does not indicate zero on the bevel scale
20
,
loosen the screws
45
that secure the scale and move the scale
asnecessary.
Checking and Adjusting the Bevel Angle (Fig.A,L,N)
The bevel override allows the max. bevel angle to be set at 45° or 48°
asrequired.
• Left = 45°
• Right = 48°
1. Make sure the override knob
46
is located in the leftposition.
2. Loosen the bevel clamp handle
19
and move the saw head to theleft.
3. This is the 45° bevelposition.
4. If adjustment is required, turn the stopscrew
47
in or out as necessary
until the pointer
44
indicates 45°.

WARNING: The guide grooves can become clogged with sawdust. Use
a stick or some low pressure air to clear the guidegrooves.
Prior to Operation

WARNING:
• Install the appropriate saw blade. Do not use excessively worn
blades. The maximum rotation speed of the tool must not exceed
that of thesawblade.
• Do not attempt to cut excessively smallpieces.
• Allow the blade to cut freely. Do notforce.
• Allow the motor to reach full speed beforecutting.
• Make sure all locking knobs and clamp handles aretight.
• Secure theworkpiece.
• Although this saw will cut wood and many nonferrous
materials,these operating instructions refer to the cutting of wood
only. The sameguide-lines apply to the other materials. Do not cut
ferrous (iron and steel) materials or masonry with this saw! Do not
use any abrasivediscs!
• Make sure to use the kerf plate. Do not operate the machine if the
kerf slot is wider than 10mm.
• Placing the workpiece on a piece of wood will increase the
capacities to 300mm.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal injury, turn
tool off and disconnect battery pack before making any
adjustments or removing/installing attachments or accessories.
An accidental start-up can causeinjury.
The attention of UK users is drawn to the “woodworking machines regulations
1974” and any subsequentamendments.
Ensure the machine is placed to satisfy your ergonomic conditions in terms
of table height and stability. The machine site shall be chosen so that the
operator has a good overview and enough free surrounding space around
the machine that allows handling of the workpiece without anyrestrictions.
To reduce effects of increased vibration, make sure the environment is not
too cold, the machine and accessory are well maintained and the workpiece
size is suitable for thismachine.
Switching On and Off (Fig.A)
The lock off switch
29
located on the the on/off trigger switch
1
must be
flipped in order for the saw to turnon.
1. To run the tool, flip the lock off switch
29
and press the on/off trigger
switch
1
.
2. To stop the tool, release thetrigger switch. The lock off switch will
re-engageautomatically.
Use of XPS™ LED Worklight System (Fig.A,R)
NOTE: The mitre saw must be connected to a powersource.
The XPS™ LED Worklight System is activated by engaging the trigger or
pressing the XPS button
34
on top of the saw housing.
To cut through an existing pencil line on a piece ofwood:
1. With the XPS light on, pull down on the operating handle
3
to bring
the saw blade
8
close to the wood. The shadow of the blade will
appear on thewood.
2. Align the pencil line with the edge of the blade’s shadow. You may
have to adjust the mitre or bevel angles in order to match the pencil
lineexactly.
Your saw is equipped with a battery fault feature. The XPS™ worklight
begins to flash when the battery is near the end of its useful charge, or
when the battery is too hot. Charge the battery prior to continuing cutting
applications. Refer to Charging A Battery for battery charginginstructions.
