ENGLISH
4. To turn dust extractor on, press the three position switch
3
to the On (I)position.
5. To use in Wireless Tool Control mode press the three position
swtich to the Wireless Tool Control ( ) position. The trigger of
the connected tool, or the button on the remote will control
the dustextractor.
NOTE: Refer to Pairing the Dust Extractor with a Tool
using Wireless Tool Control Mode to use the dust extractor
with a Wireless Tool Control equipped tool orremote.
6. When finished, turn the dust extractor off by pressing the
three position switch to the Off (O)position.
Wet Pick Up Applications (Fig. I)

WARNING: If foam or liquid escapes from the machine,
switch offimmediately.

CAUTION: Clean the water level sensors regularly and
examine it for signs ofdamage.

WARNING: Do not use the machine with this set up for
dust ClassM.
The dust extractor is designed to perform as a wet/dry unit.
Dedicated filters should be used for wet pick up applications to
avoid filterclogging.
• Make sure that the dust extractor is engaged in the
horizontalposition.
• Before wet pick up applications the dust bag must
beremoved.
• Water level sensors probes
25
will automatically shut off
the dust extractor when the maximum fill level has been
reached. Move the three position switch to the Off (O)
position, remove the battery, and empty the tank before
turning the dust extractor backon.
• To avoid syphoning, remove the dust extractor hose from
the source after the water sense probes shut down the
dustextractor.
• It is recommended that the tank be emptied of any dry
contents prior to being used for wet pick up to facilitate
tankcleaning.
• Allow filters to dry after wet pick upapplications.
To Empty Tank (Fig.A, E, F)
1. Press the three position switch
3
to the Off (O) position and
remove thebattery
7
.
2. Unlatch tank latches
4
and remove dust extractor head
6
.
3. Empty contents of tank
21
into an appropriate container
according to statutoryprovisions.
To Convert Back to Dry Vacuum Operation
(Fig.A, F)
1. Empty tank
21
, refer to Dust Extractor
Cleaninginstructions.
2. Place tank upside down position until dry. DO NOT use wet
tank for dry pickup.
3. Place dust extractor head
6
on a level surface untildry.
4. Reinstall filters when dust extractor head is dry. SeeFilters.
5. When canister is dry place the dust extractor head
6
onto
the tank and secure it by closing the tank latches
4
.
Connecting to Power Tools (Fig. A, G)

CAUTION: Follow all the requirements of the power tool
regarding connection of dustextractor.
1. Choose the correct power tool adaptor
19
to fit the power
tool connection on the tool to be used, refer to Optional
Accessories under Maintenance. Attach power tool
adaptor
19
to powertool.
2. Your D
e
WALT construction dust extractor is fitted with the
D
e
WALT AirLock connection system. The AirLock allows for a
fast, secure connection between the dust extractor hose
2
and power tool. The AirLock connector
18
connects
directly to D
e
WALT compatable tools or through the use
of an AirLock adaptor(available from your local D
e
WALT
supplier). Refer to the Optional Accessories section for
detail on availableadaptors.
NOTE: If using an adaptor, ensure it is firmly attached to the
tool outlet before following the stepsbelow.
a. Ensure the collar on the AirLock connector is in the
unlock position. (Refer to FigureG.) Align notches
20
on collar and AirLock connector as shown for unlock and
lockpositions.
b. Push the AirLock connector onto the adaptor
connectorpoint.
c. Rotate the collar to the lockedposition.
NOTE: The ball bearings inside collar lock into slot and
secure the connection.The power tool is now securely
connected to the dustextractor.
Pairing the Dust Extractor with a Tool using
Wireless Tool Control Mode (Fig. A, H)

CAUTION: When the dust extractor is being controlled
with the remote or paired power tool it may start or stop
withoutwarning.

WARNING: Do not attach the remote strap to
movingparts.
To Pair with a
DeWALT
Remote or Wireless Tool
Control Tool
1. Press the three position switch
3
to the Wireless Tool
Control ( )position.
2. Press and hold the Wireless Tool Control pairing button
11
on the DCV586M and pull the trigger on the Wireless Tool
Control equipped tool or press the button on the remote
14
at the sametime.
3. The LED
30
will be steadily illuminated to indicate a
successfulpairing.
NOTE: Only one transmitter can be paired to the DCV586M
at a time. If the unit is already paired the previous
transmitter will beoverridden.
To Unpair with a Wireless Tool Control Tool or Remote
• Press and hold the Wireless Tool Control pairing button
11
on the DCV586M and pull the trigger on the Wireless Tool
Control equipped tool or press the button on the remote at
the sametime.
• The LED
30
will flash slowly to indicate a
successfulunpairing.
