3
English
Crown Molding Fence: DW7084
Used for precision cutting of crown molding.(Page 4)
Kerf Plate Blank: DW7055
Used to limit back side tear out of material or as a replacement kerf plate.
SAW BLADES: ALWAYS USE 12" SAW BLADES WITH 1" ARBOR HOLES. SPEED
RATING MUST BE AT LEAST 4800 RPM. Never use a smaller diameter blade. It will
not be guarded properly.
D
EWALT NO. OF BLADE APPLICATION TYPE OF CUT
BLADE TEETH DESC.
RANGE
Series 20 40 Thin Kerf Gen. Purpose Smooth,
Construction Yellow Rim (Trim, Decking, Splinter Free
Coating Framing)
Series 20 60 Thin Kerf Fine Trim Very Smooth,
Construction Yellow Rim Molding Splinter Free
Coating
Series 40 40 Laser Cut Body Gen. Purpose Smooth,
Woodworking Large Carbide (Trim, Decking, Splinter Free
Teeth Framing)
Series 40 60 Laser Cut Body Fine Trim, Very Smooth,
Woodworking Large Carbide Molding Splinter Free
Teeth
Series 40 80 Laser Cut Body Fine Trim Ultra Smooth,
Woodworking Large Carbide Molding Splinter Free
Teeth Decorative
Hardwood
& Plywood
Series 40 80 Laser Cut Body Melamines, Ultra Smooth
Woodworking Large Carbide Veneers, Chip/Splinter
Teeth, Special Laminates Free
Tooth Geometry
Series 40 60 Laser Cut Body Plastics, Corian® Very Smooth
Woodworking Special Tooth and other solid Chip Free
Geometry surface materials
Series 40 80 Laser Cut Body Non-ferrous metals Very Smooth
Woodworking Special Tooth (aluminum, copper, Burr Free
Geometry brass, etc.)
Unpacking Your Saw
Check the contents of your miter saw carton to make sure that you have received all
parts. In addition to this instruction manual, the carton should contain:
1. One No. DW706 miter saw.
2. One D
EWALT 12" dia. saw blade
3. One blade wrench in wrench pocket shown in Fig. 2.
4. One DW7053 Dustbag (Some models)
DW7051
KNOBS
BRACKET
TOP HOLE
(USE FOR
DW706)
LOCKNUTS
END PLATE
DW7080
