TYP.
DW708 WIRING DIAGRAM
1
03 / 06 / 98
E12540
ARMATURE
FIELD COIL FIELD COIL
CAPACITOR
BLUE MAINS
BROWN MAINS
CONNECTOR
BLOCK
WHITE
CONNECTOR
LEAD
BLACK
CAPACITOR LEADS
BLACK
CONNECTOR
LEAD
SCHEMATIC WIRING DIAGRAM
WHITE
FIELD LEAD BLACK
CAPACITOR
LEAD
WHITE
CONNECTOR LEAD
BLACK
FIELD LEAD
BLACK
CAPACITOR
LEAD
BLACK
CONNECTOR LEAD
MAINS CORD
ELECTRICAL
CORD
BROWN
MAINS LEAD
BLACK
CONNECTOR LEAD
BLUE
MAINS LEAD
BLACK
FIELD LEAD
CAPACITOR
WHITE
FIELD LEAD
WHITE CONNECTOR
LEAD
BLACK
CAPACITOR LEAD
ENGLISH FRENCH ITALIAN
GERMAN
BLACK NOIR NERO SCHWARZ
WHITE BLANC BIANCO WEISS
BROWN BRUN MARRONE BRAUN
BLUE BLEU BLU BLAU
RED ROUGE ROSSO ROT
YELLOW JAUNE GIALLO GELB
GREEN VERT VERDE GRUN
ORANGE ORANGE ARANCIO ORANGE
GREY GRIS GRIGIO GRAU
COLOUR KEY
CLEAR
.
.
KLAR
