10
ENGLISH
When using a cable reel, always unwind the
cablecompletely.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk
of serious personal injury, turn
tool off and disconnect tool from
power source before making any
adjustments or removing/installing
attachments or accessories. Be sure
the trigger switch is in the OFF position.
An accidental start-up can causeinjury.
Attaching Side Handle (Fig. 2)
WARNING: Before using the tool, check
that the handle is tightenedsecurely.
WARNING: The side handle should
always be used to maintain control of the
tool at alltimes.
Screw the side handle(D) tightly into one of the
holes (F) on either side of the gearcase.
Mounting and Removing the Guard
(Fig. 3)
WARNING: To reduce the risk
of serious personal injury, turn
tool off and disconnect tool from
power source before making any
adjustments or removing/installing
attachments or accessories. Before
reconnecting the tool, depress and
release the trigger switch to ensure that
the tool isoff.
CAUTION: Guards must be used with
thisgrinder.
TO MOUNT THE GUARD
1. Place the angle grinder on a table, spindleup.
2. Press the guard (C) down (Fig. 3A).
3. Position the guard between your body and
workpiece.
4. Tight the screw (L) holding the cinch collar
firmly around the neck of spindle (Fig. 3B)
TO REMOVE THE GUARD
1. Loosen the screw (L) holding the cinch collar
around the neck of thespindle and make sure
the screw remains attached to the collar.
remain attached to the collar..
2. Lift up on theguard.
• This product is not intended for use by persons
(including children) suffering from diminished
physical, sensory or mental abilities; lack of
experience, knowledge or skills unless they are
supervised by a person responsible for their
safety. Children should never be left alone with
thisproduct.
Soft Start Feature
The soft start feature allows a slow speed build-up
to avoid an initial jerk when starting. This feature is
particularly useful when working in confinedspaces.
No-Volt
The No-volt function stops the grinder restarting
without the switch being cycled if there is a break in
the powersupply.
Electrical Safety
The electric motor has been designed for one
voltage only. Always check that the power supply
corresponds to the voltage on the ratingplate.
Your DEWALT tool is double insulated in
accordance with EN60745; therefore no
earth wire isrequired.
WARNING: 115 V units have
to be operated via a fail-safe
isolating transformer with an earth
screen between the primary and
secondarywinding.
If the supply cord is damaged, it must be replaced
by a specially prepared cord available through the
D
EWALT serviceorganisation.
Mains Plug Replacement
(U.K. & Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the oldplug.
• Connect the brown lead to the live terminal in
theplug.
• Connect the blue lead to the neutralterminal.
WARNING: No connection is to be
made to the earthterminal.
Follow the fitting instructions supplied with good
quality plugs. Recommended fuse: 13A.
Using an Extension Cable
If an extension cable is required, use an approved
3–core extension cable suitable for the power input
of this tool (see Technical Data).The minimum
conductor size is 1.5 mm
2
; the maximum length
is 30m.
