6
ENGLISH
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
EC-Declaration of Conformity
Machinery Directive
Table Saw
DWE7485
declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN62841-1:2015+AC:2015,
EN62841-3-1:2014+AC:2015 + A11:2017.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact
at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of
.
Markus Rompel
Vice-President Engineering, PTE-Europe
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
09.08.2019
the job. This may significantly reduce the exposure level
over the total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration and/or noise such as: maintain
the tool and the accessories, keep the hands warm
(relevant for vibration), organisation of workpatterns.
The vibration and/or noise emission level given in this
information sheet has been measured in accordance with
a standardised test given in EN62841 and may be used to
compare one tool with another. It may be used for a preliminary
assessment ofexposure.
WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/or
noise should also take into account the times when the tool
is switched off or when it is running but not actually doing
DWE7485
(QS, GB)
DWE7485
(XE)
DWE7485
(LX)
Voltage V
DC
230 220–240 115
Type 1 1 1
Rated input power W 1850 1850 1700
No load speed min
-1
5800 5800 5800
Blade diameter mm 210 210 210
Blade bore mm 30 30 30
Blade kerf mm 1.8 1.8 1.8
Blade body thickness mm 1.3 1.3 1.3
Riving knife thickness mm 1.6 1.6 1.6
Depth of cut at 90° mm 65 65 65
Depth of bevel cut at 45° mm 45 45 45
Ripping capacity
(Right of blade)
mm 622.3 622.3 622.3
Ripping capacity (Left of blade) mm 318 318 318
Work surface dimensions mm 485 x 485 485 x 485 485 x 485
Overall dimensions mm 605 x 605
x 330
605 x 605
x 330
605 x 605
x 330
Weight kg 22 22 22
Noise values and/or vibration values (triax vector sum) according to
EN62841-1-2015:
L
PA
(emission sound pressure
level)
dB(A) 90 90 91
L
WA
(sound power level) dB(A) 107 107 108
K (uncertainty for the given
sound level)
dB(A) 3 3 3
English (original instructions)
Congratulations!
You have chosen a
tool. Years of experience, thorough
product development and innovation make
one of the
most reliable partners for professional power toolusers.
Technical Data
TABLE SAW
DWE7485
