DeWalt DXAEC210 User Manual

English
11
ASSEMBLY:
Ø8mm Plain Washers
Wheel Shaft
Wheels
Ø6mm
Spring
Washer
Wheel Nuts
Wheel Covers
Ø6mm
Plain
Washer
Ø6mm
Plain
Washer
Ø6mm
Spring
Washer
Wheel Nuts
Wheel Covers
1. Align one Wheel Set (Ø8mm Plain Washer, Wheel, Ø6mm Plain
Washer, Ø6mm Spring Washer and Wheel Nut, assembled in the
sequence shown in the illustration) and attach to each end of the
Wheel Shaft.
2. Screw the Wheel Nuts for each end of the Wheel Shaft.
3. Snap the Wheel Covers into the centre slot of each Wheel.
DXAEC210_ManualENFRSP_092116.indd 11 10/19/2016 3:58:53 PM
