DeWalt DXAEC2CA - Main Unit Components; Connectors and Cables

English
7
Main Unit Components (Fig. 1)
A. 6V / 12V Switch
B. Mounting Brackets (x4)
C. (Reverse Polarity) Fault LED
D. Charging LED
E. Full (Charging Complete)
LED
F. Collapsible Hanging Hook
FRONT OF UNIT
C D E
AA
B B
BB
BACK OF UNIT
F
Connectors and Cables (Fig. 2)
G. Double Barrel Charger
Connector (connects to
Battery Clamps or Battery
Terminal Rings)
H. AC Plug
I. Battery Clamps
J. Battery Terminal Rings
H
G
IIIII J
