LCD Screen (Fig. 3)
A. Battery Reconditioning
Icons
B. Battery Recondition
Indicator
C. High Temperature
Compensation Icon
D. Low Temperature
Compensation Icon
E. Digital Display (varies by
function)
F. Seconds/Voltage/Ampere/
Percentage Indicator
G. DC Power Supply Mode
Indicator
H. Bank 1 Indicator
I. Bank 2 Indicator
B
A
S
C D E F HG
J
K
L
A
MNOPR
Q
I
J. USB Icon
K. Fault Icon
L. Alternator Good/Fault
Indicators
M. Alternator Icon
N. Pump Engine Icon
O. Overheat Alarm Icon
P. Alarm Icon
Q. Clamp Icons
R. Reverse Polarity Icons
S. Battery Icon
